■AEC-Q200 Murata Standard Specification and Test Methods
No
AEC-Q200 Test Item
Specification.
AEC-Q200 Test Method
14 Thermal Shock
The measured and observed characteristics should satisfy the
specifications in the following table.
Solder the capacitor on the test substrate(glass epoxy board).
Perform the 300 cycles according to the two heat treatments listed
in the following table(Maximum transfer time is 20s).
Appearance
No marking defects
Set for 24+/-2h at room temperature, then measure.
Capacitance
Change
Within +/-10.0%
Step
1
2
Temp.(℃） Min.Operating Temp.+0/-3
Max.Operating Temp.+3/-0
D.F.
Within the specified initial value.
Within the specified initial value.
Time
15+/-3
(min.）
15+/-3
・ Initial measurement
Perform a heat treatment at 150+0/-10 ℃for 1h and then sit
I.R.
for 24+/-2h at room temperature.Perform the initial measurement.
25℃
15 ESD
Appearance
Capacitance
D.F.
No marking defects
Per AEC-Q200-002
Within the specified initial value.
Within the specified initial value.
I.R.
Within the specified initial value.
25℃
95% of the terminations is to be soldered evenly and continuously.
16 Solderability
(a) Preheat at 155℃ for 4h. After preheating, immerse the capacitor
ꢀꢀ in a solution of rosin ethanol 25(mass)%.
ꢀ Immerse in Sn-3.0Ag-0.5Cu solder solution at 245+/-5℃ or
an eutectic solder solution at 235+/-5℃ for 5+0/-0.5s.
(b) should be placed into steam aging for 8h+/-15min.
ꢀꢀ After preheating, immerse the capacitor in a solution of rosin
ꢀ ꢀethanol 25(mass)%.
ꢀ ꢀImmerse in Sn-3.0Ag-0.5Cu solder solution at 245+/-5℃
ꢀ ꢀor an eutectic solder solution at 235+/-5℃ for 5+0/-0.5s.
(c) should be placed into steam aging for 8h+/-15min.
ꢀ ꢀAfter preheating, immerse the capacitor in a solution of rosin
ꢀ ꢀethanol 25(mass)%.
ꢀꢀImmerse in Sn-3.0Ag-0.5Cu solder solution or
an eutectic solder solution for 120+/-5s at 260+/-5℃.
17 Electrical Appearance
Chatacteri-
No defects or abnormalities
Visual inspection.
The capacitance/D.F. should be measured at 25℃ at the
zation
Capacitance
Shown in Rated value.
0.025 max.
frequency and voltage shown in the table.
D.F.
Char.
10V min.
(C≦10μF)
Item
Frequency
Voltage
1.0+/-0.1kHz
1.0+/-0.2Vrms
The insulation resistance should be measured with a DC voltage not
exceeding the rated voltage at 25℃ and 125℃ within 2minutes of
charging.
I.R.ꢀ25℃
More than 10,000MΩ or 500Ω・F
(Whichever is smaller)
I.R.ꢀ125℃
More than 1,000MΩ or 10Ω・F
(Whichever is smaller)
No failure should be observed when 250% of the rated voltage is
applied between the terminations for 1 to 5s, provided the
charge/discharge current is less than 50mA.
Dielectric
Strength
No failure
JEMCGS-00806D
4
