• Please read rating and !CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
!Note
C85E.pdf
Jul.13,2011
DEC Series (SCpleacsisf1ic,a2ti/oDnCs6a.n3dkVT)eSspt eMceiftihcoadtisons and Test Methods
Continued from the preceding page.
No.
Item
Appearance
Specifications
No marked defect
Test Method
First the capacitor should be
Capacitor
1.5
Thermal
Screen
stored at 120+0/-5°C for
60+0/-5 sec.
Char. SL: Within ±2.5%
Char. B: Within ±5%
Char. E: Within ±15%
Capacitance
Change
Then, as in the figure, the lead
wires should be immersed in
solder of 260+0/-5°C up to 1.5 to
2.0mm from the root of terminal
for 7.5+0/-1 sec.
to 2.0mm
Molten
Solder
Soldering Effect
(On-Preheat)
13
Pre-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
before initial measurements. (Char. B, E)
Post-treatment: Capacitor should be stored for 1 to 2 hrs. at
room condition.*1 (Char. SL)
Dielectric Strength
(Between Lead
Wires)
Per item 4.
Post-treatment: Capacitor should be stored for 4 to 24 hrs. at
room condition.*1 (Char. B, E)
Appearance
No marked defect
The capacitor should be subjected to 5 temperature cycles,
then consecutively to 2 immersion cycles.
Char. SL: Within ±3%
Char. B: Within ±10%
Char. E: Within ±20%
Capacitance
Change
<Temperature Cycle>
Step Temperature (°C) Time (min)
Char. SL: 275+5/2C*2min. (30pF under)
350 min. (30pF min.)
1
2
3
4
-25±3
Room Temp.
85±3
30
3
30
3
Q
D.F.
I.R.
Char. B, E: 4.0% max.
Room Temp.
2000MΩ min.
Temperature
Cycle time: 5 cycles
14 and Immersion
Cycle
<Immersion Cycle>
Step Temperature (°C) Time (min) Immersion Water
1
2
65+5/-0
0±3
15
15
Clean water
Salt water
Cycle time: 2 cycles
Dielectric Strength
(Between Lead
Wires)
Per item 4.
Pre-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
before initial measurements. (Char. B, E)
Post-treatment: Capacitor should be stored for 4 to 24 hrs. at
room condition.*1
Appearance
No marked defect
Set the capacitor for 500+24/-0 hrs. at 40±2°C in 90 to 95%
relative humidity.
Char. SL: Within ±5%
Char. B: Within ±10%
Char. E: Within ±20%
Capacitance
Change
Pre-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
before initial measurements. (Char. B, E)
Post-treatment: Capacitor should be stored for 1 to 2 hrs. at
room condition.*1
Humidity (Under
15
Steady State)
Char. SL: 275+5/2C*2min. (30pF under)
350 min. (30pF min.)
10
Q
D.F.
Char. B, E: 5.0% max.
1000MΩ min.
I.R.
Appearance
No marked defect
Apply the rated voltage for 500+24/-0 hrs. at 40±2°C in 90 to
95% relative humidity. (Charge/Discharge currentV50mA.)
Pre-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
before initial measurements. (Char. B, E)
Post-treatment: Capacitor should be stored for 1 to 2 hrs. at
room condition.*1 (Char. SL)
Post-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
(Char. B, E)
Char. SL: Within ±7.5%
Char. B: Within ±10%
Char. E: Within ±20%
Capacitance
Change
Humidity
16
Char. SL:
100+10/3C*2min. (30pF under)
200 min. (30pF min.)
Loading
Q
D.F.
Char. B, E: 5.0% max.
500MΩ min.
I.R.
Appearance
No marked defect
Apply a DC voltage of 150% of the rated voltage for
1000+48/-0 hrs. at 85±2°C with a relative humidity of 50% max.
(Charge/Discharge currentV50mA.)
Pre-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
before initial measurements. (Char. B, E)
Post-treatment: Capacitor should be stored for 1 to 2 hrs. at
room condition.*1 (Char. SL)
Post-treatment: Capacitor should be stored at 85±2°C for 1 hr.,
then placed at room condition*1 for 24±2 hrs.
(Char. B, E)
Char. SL: Within ±3%
Char. B: Within ±10%
Char. E: Within ±20%
Capacitance
Change
Char. SL: 275+5/2C*2min. (30pF under)
350 min. (30pF min.)
17 Life
Q
D.F.
I.R.
Char. B, E: 4.0% max.
2000MΩ min.
*1 "Room condition" Temperature: 15 to 35°C, Relative humidity: 45 to 75%, Atmospheric pressure: 86 to 106kPa
*2 "C" expresses nominal capacitance value (pF).
