• Please read rating and !CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
!Note
C85E.pdf
Jul.13,2011
High Voltage Ceramic Capacitors
DEB Series (Class 2/DC1k-3.15kV)
<Fig. 1>
T max.
<Fig. 2>
T max.
D max.
Features
1. Small size and high capacitance
2. Coated with flame-retardant epoxy resin
(equivalent to UL94V-0 standard).
Please contact us when a halogen-free product*
is necessary.
e
F±1.0
ø d
* Cl=900ppm max., Br=900ppm max. and
Cl+Br=1500ppm max.
(in mm)
Lead Code Coating Extension e
ø d
Style
Up to the end of crimp 0.6±0.05 Fig. 1
A2, A3
C1, CD
C3
3. Taping available for automatic insertion.
[Bulk]
3.0 max.
3.0 max.
0.5±0.05 Fig. 2
0.6±0.05 Fig. 2
Vertical Crimp Long (Fig. 1)
Straight Long (Fig. 2)
Applications
Ideal for use on decoupling circuits for power supplies.
<Fig. 1>
T max.
<Fig. 2>
T max.
D max.
Do not use these products in any automotive
power train or safety equipment including battery
chargers for electric vehicles and plug-in hybrids.
Only Murata products clearly stipulated as
"for Automotive use" on its catalog can be used
for automobile applications such as power train and
safety equipment.
e
ø d
F±0.8
(in mm)
Lead Code Coating Extension e
ø d
Style
Up to the end of crimp 0.6±0.05 Fig. 1
B2, B3
D1, DD
D3
[Bulk]
3.0 max.
3.0 max.
0.5±0.05 Fig. 2
0.6±0.05 Fig. 2
Vertical Crimp Short (Fig. 1)
Straight Short (Fig. 2)
9
Marking
Temp. Char.
B
E
F
Nominal Body Diameter
221
102
102
ø4.5-5mm
ø6mm
3KV
1KV
2KV
331
3KV
66
102
2KV
66
222
1KV
66
102K
3KV
66
102Z
3KV
66
472Z
2KV
66
ø7-9mm
B
E
103Z
2KV
66
332K
3KV
66
472Z
3KV
66
ø10-16mm
Marked with code for char. B and E (omitted for nominal body diameter ø9mm and under)
Marked with 3 figures
Temperature Characteristics
Nominal Capacitance
Marked with code (omitted for nominal body diameter ø6mm and under)
Marked with code (for DC3.15kV, marked with 3KV)
Capacitance Tolerance
Rated Voltage
Marked with
(omitted for nominal body diameter ø9mm and under)
Manufacturer's Identification
Manufactured Date Code
Abbreviation (omitted for nominal body diameter ø5mm and under)
44
