DEA Series (125°C Guaranteed / Class1 / DC1kV-3.15kV) Spec ica ons and Test Methods
DEA Series Specificifatiotins and Test Methods
Continued from the preceding page.
No.
Item
Specifications
No marked defect
Test Method
First the capacitor should be
stored at 120+0/-5°C for
60+0/-5 sec.
Appearance
Capacitor
1.5
Thermal
Screen
Capacitance
Change
Within ±2.5%
Then, as in the figure, the lead
wires should be immersed in
solder of 260+0/-5°C up to 1.5 to
2.0mm from the root of terminal
for 7.5+0/-1 sec.
to 2.0mm
Soldering Effect
(On-Preheat)
Molten
Solder
13
Dielectric Strength
(Between Lead
Wires)
Per item 4.
Post-treatment:
Capacitor should be stored for 1 to 2 hrs. at room condition.*1
Appearance
No marked defect
Within ±5%
The capacitor should be subjected to 5 temperature cycles.
<Temperature Cycle>
Capacitance
Change
Step Temperature (°C) Time (min)
1
2
3
4
-25±3
Room Temp.
125±3
30
3
30
3
275+5/2C*2min. (30pF under)
350 min. (30pF min.)
Temperature
Cycle
Q
14
Room Temp.
I.R.
1000MΩ min.
Cycle time: 5 cycles
Dielectric Strength
(Between Lead
Wires)
Post-treatment:
Per item 4.
Capacitor should be stored for 1 to 2 hrs. at room condition.*1
Appearance
No marked defect
Within ±5%
Set the capacitor for 500+24/-0 hrs. at 40±2°C in 90 to 95%
relative humidity.
Capacitance
Change
Humidity (Under
Steady State)
15
275+5/2C*2min. (30pF under)
350 min. (30pF min.)
Post-treatment:
Capacitor should be stored for 1 to 2 hrs. at room condition.*1
Q
I.R.
1000MΩ min.
Appearance
No marked defect
Apply the rated voltage for 500+24/-0 hrs. at 40±2°C in 90 to
95% relative humidity.
(Charge/Discharge currentV50mA)
Post-treatment:
Capacitor should be stored for 1 to 2 hrs. at room condition.*1
Capacitance
Change
Within ±5%
8
Humidity
Loading
16
275+5/2C*2min. (30pF under)
350 min. (30pF min.)
Q
I.R.
1000MΩ min.
Appearance
No marked defect
Apply a DC voltage of 150% of the rated voltage for
1000+48/-0 hrs. at 125±2°C with a relative humidity of 50%
max. (Charge/Discharge currentV50mA)
Post-treatment:
Capacitor should be stored for 1 to 2 hrs. at room condition.*1
Capacitance
Change
Within ±3%
17 Life
275+5/2C*2min. (30pF under)
350 min. (30pF min.)
Q
I.R.
2000MΩ min.
*1 "Room condition" Temperature: 15 to 35°C, Relative humidity: 45 to 75%, Atmospheric pressure: 86 to 106kPa
*2 "C" expresses nominal capacitance value (pF).
