• Please read rating and !CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
!Note
C85E.pdf
Jul.13,2011
Continued from the preceding page.
DC Rated
Voltage
(V)
Lead
Lead
Lead
Package
Taping
Capacitance
(pF)
Body Dia. D
(mm)
Lead Spacing F
(mm)
Body Thickness T
(mm)
Part Number
Package
Package
Long Bulk Short Bulk
DEA1X3F680Jppp
DEA1X3F820Jppp
DEA1X3F101Jppp
DEA1X3F121Jppp
DEA1X3F151Jppp
DEA1X3F181Jppp
DEA1X3F221Jppp
DEA1X3F271Jppp
DEA1X3F331Jppp
DEA1X3F391Jppp
3150
3150
3150
3150
3150
3150
3150
3150
3150
3150
68 ±5%
82 ±5%
8
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
7.5
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
6.0
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
A3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
B3B
N3A
N3A
N3A
N3A
N3A
N3A
N3A
N7A
N7A
N7A
8
100 ±5%
120 ±5%
150 ±5%
180 ±5%
220 ±5%
270 ±5%
330 ±5%
390 ±5%
9
10
11
11
12
14
15
16
Three blank columns are filled with the lead and packaging codes. Please refer to the three columns on the right for the appropriate code.
8
41
