• Please read rating and !CAUTION (for storage, operating, rating, soldering, mounting and handling) in this catalog to prevent smoking and/or burning, etc.
• This catalog has only typical specifications because there is no space for detailed specifications. Therefore, please review our product specifications or consult the approval sheet for product specifications before ordering.
!Note
C85E.pdf
Jul.13,2011
High Voltage Ceramic Capacitors
DEA Series (125°C Guaranteed/Class 1/DC1k-3.15kV)
<Fig. 1>
T max.
<Fig. 2>
T max.
D max.
■ Features
1. Temperature compensating type ceramics realize lower
heat dissipation than DEH/DES series.
2. Operating temperature range is guaranteed up to 125
degrees C.
e
3. Coated with flame-retardant epoxy resin
F±1.0
ø d
(equivalent to UL94V-0 standard).
Please contact us when a halogen-free product*
is necessary.
(in mm)
Lead Code Coating Extension e
ø d
Style
Up to the end of crimp 0.6±0.05 Fig. 1
A2, A3
C1, CD
C3
[Bulk]
3.0 max.
3.0 max.
0.5±0.05 Fig. 2
0.6±0.05 Fig. 2
Vertical Crimp Long (Fig. 1)
Straight Long (Fig. 2)
* Cl=900ppm max., Br=900ppm max. and
Cl+Br=1500ppm max.
4. Taping available for automatic insertion.
<Fig. 1>
T max.
<Fig. 2>
T max.
D max.
■ Applications
1. Ideal for use as the ballast in backlighting
inverters for liquid crystal display.
e
2. Ideal for use on high-frequency pulse circuits such
as a horizontal resonance circuit for CTV and snubber
circuits for switching power supplies.
ø d
F±0.8
(in mm)
Lead Code Coating Extension e
ø d
Style
Do not use these products in any automotive
power train or safety equipment including battery
chargers for electric vehicles and plug-in hybrids.
Only Murata products clearly stipulated as
"for Automotive use" on its catalog can be used
for automobile applications such as power train and
safety equipment.
8
Up to the end of crimp 0.6±0.05 Fig. 1
B2, B3
D1, DD
D3
[Bulk]
3.0 max.
3.0 max.
0.5±0.05 Fig. 2
0.6±0.05 Fig. 2
Vertical Crimp Short (Fig. 1)
Straight Short (Fig. 2)
■ Marking
Temp. Char.
SL
Nominal Body Diameter
68
ø4.5-5mm
ø6mm
1KV
39
3KV
66
181J
2KV
66
ø7-9mm
391J
3KV
66
ø10-16mm
Under 100pF: Actual value, 100pF and over: Marked with 3 figures
Nominal Capacitance
Capacitance Tolerance
Rated Voltage
Marked with code (omitted for nominal body diameter ø6mm and under)
Marked with code (for DC3.15kV, marked with 3KV)
Marked with
(omitted for nominal body diameter ø9mm and under)
Manufacturer's Identification
Manufactured Date Code
Abbreviation (omitted for nominal body diameter ø5mm and under)
39
MURATA [ muRata ]
