Appendix: 68HC912D60A EEPROM
PROTLCK — Block Protect Write Lock
0 = Block protect bits and bulk erase protection bit can be written
1 = Block protect bits are locked
Read anytime. Write once in normal modes (SMODN = 1), set and
clear any time in special modes (SMODN = 0).
DMY— Dummy bit
Read and write anytime.
EEPROT — EEPROM Block Protect
$00F1
Bit 7
SHPROT
1
6
1
1
5
BPROT5
1
4
BPROT4
1
3
BPROT3
1
2
BPROT2
1
1
BPROT1
1
Bit 0
BPROT0
1
RESET:
Prevents accidental writes to EEPROM. Read anytime. Write anytime if
EEPGM = 0 and PROTLCK = 0.
SHPROT — SHADOW Word Protection
0 = The SHADOW word can be programmed and erased.
1 = The SHADOW word is protected from being programmed and
erased.
BPROT[5:0] — EEPROM Block Protection
0 = Associated EEPROM block can be programmed and erased.
1 = Associated EEPROM block is protected from being
programmed and erased.
Table 23-22. K byte EEPROM Block Protection
Bit Name
BPROT5
BPROT4
BPROT3
BPROT2
BPROT1
BPROT0
Block Protected
$0800 to $0BFF
$0C00 to $0DFF
$0E00 to $0EFF
$0F00 to $0F7F
$0F80 to $0FBF
$0FC0 to $0FFF
Block Size
1024 Bytes
512 Bytes
256 Bytes
128 Bytes
64 Bytes
64 Bytes
Advance Information
412
68HC(9)12D60 — Rev 4.0
MOTOROLA
Appendix: 68HC912D60A EEPROM
