Freescale Semiconductor, Inc.
Advance Information — 68HC(9)12D60
Section 13. Pulse Width Modulator
13.1 Contents
13.2 Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .181
13.3 PWM Register Description . . . . . . . . . . . . . . . . . . . . . . . . . . .184
13.4 PWM Boundary Cases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .196
13.2 Introduction
The pulse-width modulator (PWM) subsystem provides four
independent 8-bit PWM waveforms or two 16-bit PWM waveforms or a
combination of one 16-bit and two 8-bit PWM waveforms. Each
waveform channel has a programmable period and a programmable
duty-cycle as well as a dedicated counter. A flexible clock select scheme
allows four different clock sources to be used with the counters. Each of
the modulators can create independent, continuous waveforms with
software-selectable duty rates from 0 percent to 100 percent. The PWM
outputs can be programmed as left-aligned outputs or center-aligned
outputs.
The period and duty registers are double buffered so that if they change
while the channel is enabled, the change will not take effect until the
counter rolls over or the channel is disabled. If the channel is not
enabled, then writes to the period and/or duty register will go directly to
the latches as well as the buffer, thus ensuring that the PWM output will
always be either the old waveform or the new waveform, not some
variation in between.
A change in duty or period can be forced into immediate effect by writing
the new value to the duty and/or period registers and then writing to the
counter. This causes the counter to reset and the new duty and/or period
values to be latched. In addition, since the counter is readable it is
