MITSUBISHI MICROCOMPUTERS
3822 Group
SINGLE-CHIP 8-BIT CMOS MICROCOMPUTER
Table 17 Recommended operating conditions (Standard, One Time PROM version)
(VCC = 2.5 to 5.5 V, Ta = –20 to 85 °C, unless otherwise noted)
Limits
Typ.
Symbol
Parameter
Unit
Min.
Max.
–40
–40
40
“H” total peak output current
“H” total peak output current
“L” total peak output current
“L” total peak output current
“H” total average output current
“H” total average output current
“L” total average output current
“L” total average output current
“H” peak output current
ΣIOH(peak)
ΣIOH(peak)
ΣIOL(peak)
ΣIOL(peak)
ΣIOH(avg)
ΣIOH(avg)
ΣIOL(avg)
ΣIOL(avg)
IOH(peak)
IOH(peak)
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
P00–P07, P10–P17, P20–P27 (Note 1)
P41–P47, P50–P57, P60–P67, P70, P71 (Note 1)
P00–P07, P10–P17, P20–P27 (Note 1)
P41–P47, P50–P57, P60–P67, P70, P71 (Note 1)
P00–P07, P10–P17, P20–P27 (Note 1)
P41–P47, P50–P57, P60–P67, P70, P71 (Note 1)
P00–P07, P10–P17, P20–P27 (Note 1)
P41–P47, P50–P57, P60–P67, P70, P71 (Note 1)
P00–P07, P10–P17 (Note 2)
40
–20
–20
20
20
–2
“H” peak output current
–5
P20–P27, P41–P47, P50–P57, P60–P67, P70, P71
(Note 2)
IOL(peak)
IOL(peak)
5
“L” peak output current
“L” peak output current
mA
mA
P00–P07, P10–P17 (Note 2)
10
P20–P27, P41–P47, P50–P57, P60–P67, P70, P71
(Note 2)
–1.0
–2.5
IOH(avg)
IOH(avg)
“H” average output current
“H” average output current
mA
mA
P00–P07, P10–P17 (Note 3)
P20–P27, P41–P47, P50–P57, P60–P67, P70, P71
(Note 3)
mA
mA
“L” average output current
“L” average output current
2.5
5.0
IOL(avg)
IOL(avg)
P00–P07, P10–P17 (Note 3)
P20–P27, P41–P47, P50–P57, P60–P67, P70, P71
(Note 3)
(4.0 V ≤ VCC ≤ 5.5 V)
(2.5 V ≤ VCC ≤ 4.0 V)
4.0
MHz
f(CNTR0)
f(CNTR1)
Input frequency for timers X and Y
(duty cycle 50%)
(2ꢀVCC)-4 MHz
8.0 MHz
(4ꢀVCC)-8 MHz
High-speed mode
(4.0 V ≤ VCC ≤ 5.5 V)
Main clock input oscillation frequency
(Note 4)
f(XIN)
High-speed mode
(2.5 V ≤ VCC ≤ 4.0 V)
Middle-speed mode
8.0
50
MHz
kHz
f(XCIN)
Sub-clock input oscillation frequency (Notes 4, 5)
32.768
Notes 1: The total output current is the sum of all the currents flowing through all the applicable ports. The total average current is an average value mea-
sured over 100 ms. The total peak current is the peak value of all the currents.
2: The peak output current is the peak current flowing in each port.
3: The average output current is an average value measured over 100 ms.
4: When the oscillation frequency has a duty cycle of 50 %.
5: When using the microcomputer in low-speed mode, make sure that the sub-clock input oscillation frequency on condition that f(XCIN) < f(XIN)/3.
49
