PIC18F2480/2580/4480/4580
SLEEP
Enter Sleep mode
SUBFWB
Subtract f from W with Borrow
Syntax:
SLEEP
None
Syntax:
SUBFWB f {,d {,a}}
Operands:
Operation:
Operands:
0 ≤ f ≤ 255
d ∈ [0,1]
a ∈ [0,1]
00h → WDT,
0 → WDT postscaler,
1 → TO,
Operation:
(W) – (f) – (C) → dest
0 → PD
Status Affected:
Encoding:
N, OV, C, DC, Z
Status Affected:
Encoding:
TO, PD
0101
01da
ffff
ffff
0000
0000
0000
0011
Description:
Subtract register ‘f’ and Carry flag
(borrow) from W (2’s complement
method). If ‘d’ is ‘0’, the result is stored
in W. If ‘d’ is ‘1’, the result is stored in
register ‘f’.
Description:
The Power-Down Status bit (PD) is
cleared. The Time-out Status bit (TO)
is set. Watchdog Timer and its
postscaler are cleared.
The processor is put into Sleep mode
with the oscillator stopped.
If ‘a’ is ‘0’, the Access Bank is selected.
If ‘a’ is ‘1’, the BSR is used to select the
GPR bank.
Words:
Cycles:
1
1
If ‘a’ is ‘0’ and the extended instruction
set is enabled, this instruction operates
in Indexed Literal Offset Addressing
mode whenever f ≤ 95 (5Fh). See
Section 26.2.3 “Byte-Oriented and
Bit-Oriented Instructions in Indexed
Literal Offset Mode” for details.
Q Cycle Activity:
Q1
Q2
Q3
Q4
Decode
No
operation
Process
Data
Go to
Sleep
Words:
Cycles:
1
1
Example:
SLEEP
Before Instruction
Q Cycle Activity:
Q1
TO
PD
=
=
?
?
Q2
Q3
Q4
After Instruction
Decode
Read
register ‘f’
Process
Data
Write to
destination
TO
PD
=
=
1 †
0
Example 1:
SUBFWB
REG, 1, 0
Before Instruction
†
If WDT causes wake-up, this bit is cleared.
REG
W
=
=
=
3
2
1
C
After Instruction
REG
W
C
=
FF
2
=
=
=
=
0
Z
0
1
N
; result is negative
Example 2:
Before Instruction
SUBFWB
REG, 0, 0
REG
W
C
=
=
=
2
5
1
After Instruction
REG
W
C
=
2
3
1
0
=
=
=
=
Z
N
0
; result is positive
Example 3:
Before Instruction
SUBFWB
REG, 1, 0
REG
W
C
=
=
=
1
2
0
After Instruction
REG
W
C
=
0
2
1
1
0
=
=
=
=
Z
; result is zero
N
DS39637D-page 402
© 2009 Microchip Technology Inc.
