PIC18F2480/2580/4480/4580
RLNCF
Rotate Left f (No Carry)
RRCF
Rotate Right f through Carry
Syntax:
RLNCF f {,d {,a}}
Syntax:
RRCF f {,d {,a}}
Operands:
0 ≤ f ≤ 255
d ∈ [0,1]
a ∈ [0,1]
Operands:
0 ≤ f ≤ 255
d ∈ [0,1]
a ∈ [0,1]
Operation:
(f<n>) → dest<n + 1>,
(f<7>) → dest<0>
Operation:
(f<n>) → dest<n – 1>,
(f<0>) → C,
(C) → dest<7>
Status Affected:
Encoding:
N, Z
Status Affected:
Encoding:
C, N, Z
0100
01da
ffff
ffff
0011
00da
ffff
ffff
Description:
The contents of register ‘f’ are rotated
one bit to the left. If ‘d’ is ‘0’, the result
is placed in W. If ‘d’ is ‘1’, the result is
stored back in register ‘f’.
Description:
The contents of register ‘f’ are rotated
one bit to the right through the Carry
flag. If ‘d’ is ‘0’, the result is placed in W.
If ‘d’ is ‘1’, the result is placed back in
register ‘f’.
If ‘a’ is ‘0’, the Access Bank is selected.
If ‘a’ is ‘1’, the BSR is used to select the
GPR bank.
If ‘a’ is ‘0’, the Access Bank is selected.
If ‘a’ is ‘1’, the BSR is used to select the
GPR bank.
If ‘a’ is ‘0’ and the extended instruction
set is enabled, this instruction operates
in Indexed Literal Offset Addressing
mode whenever f ≤ 95 (5Fh). See
Section 26.2.3 “Byte-Oriented and
Bit-Oriented Instructions in Indexed
Literal Offset Mode” for details.
If ‘a’ is ‘0’ and the extended instruction
set is enabled, this instruction operates
in Indexed Literal Offset Addressing
mode whenever f ≤ 95 (5Fh). See
Section 26.2.3 “Byte-Oriented and
Bit-Oriented Instructions in Indexed
Literal Offset Mode” for details.
register f
register f
C
Words:
Cycles:
1
1
Words:
Cycles:
1
1
Q Cycle Activity:
Q1
Q2
Q3
Q4
Q Cycle Activity:
Q1
Decode
Read
register ‘f’
Process
Data
Write to
destination
Q2
Q3
Q4
Decode
Read
register ‘f’
Process
Data
Write to
destination
Example:
RLNCF
REG, 1, 0
Before Instruction
REG
After Instruction
Example:
RRCF
REG, 0, 0
=
1010 1011
0101 0111
Before Instruction
REG
=
REG
C
=
=
1110 0110
0
After Instruction
REG
W
C
=
=
=
1110 0110
0111 0011
0
DS39637D-page 400
© 2009 Microchip Technology Inc.
