PIC18F6525/6621/8525/8621
TABLE 1-2:
PIC18F6525/6621/8525/8621 PINOUT I/O DESCRIPTIONS (CONTINUED)
Pin Number
Pin
Type
Buffer
Type
Pin Name
Description
PIC18F6X2X
PIC18F8X2X
PORTE is a bidirectional I/O port.
RE0/AD8/RD/P2D
RE0
2
4
I/O
I/O
I
ST
TTL
TTL
—
Digital I/O.
(3)
AD8
RD
P2D
External memory address/data 8.
Read control for Parallel Slave Port.
ECCP2 output P2D.
O
RE1/AD9/WR/P2C
RE1
1
3
I/O
I/O
I
ST
TTL
TTL
ST
Digital I/O.
(3)
AD9
WR
P2C
External memory address/data 9.
Write control for Parallel Slave Port.
ECCP2 output P2C.
O
RE2/AD10/CS/P2B
RE2
64
78
I/O
I/O
I
ST
TTL
TTL
—
Digital I/O.
(3)
AD10
CS
P2B
External memory address/data 10.
Chip select control for Parallel Slave Port.
ECCP2 output P2B.
O
RE3/AD11/P3C
RE3
63
62
61
60
59
77
76
75
74
73
I/O
I/O
O
ST
TTL
—
Digital I/O.
External memory address/data 11.
ECCP3 output P3C.
(3)
AD11
(4)
P3C
RE4/AD12/P3B
RE4
I/O
I/O
O
ST
TTL
—
Digital I/O.
External memory address/data 12.
ECCP3 output P3B.
(3)
AD12
P3B
(4)
RE5/AD13/P1C
RE5
I/O
I/O
O
ST
TTL
—
Digital I/O.
External memory address/data 13.
ECCP1 output P1C.
(3)
AD13
P1C
(4)
RE6/AD14/P1B
RE6
I/O
I/O
O
ST
TTL
—
Digital I/O.
External memory address/data 14.
ECCP1 output P1B.
(3)
AD14
P1B
(4)
RE7/AD15/ECCP2/P2A
RE7
I/O
I/O
I/O
ST
TTL
ST
Digital I/O.
(3)
AD15
External memory address/data 15.
Enhanced Capture 2 input, Compare 2
output, PWM 2 output.
(5)
ECCP2
(5)
P2A
O
—
ECCP2 output P2A.
Legend: TTL = TTL compatible input
ST = Schmitt Trigger input with CMOS levels
= Input
= Power
CMOS = CMOS compatible input or output
Analog = Analog input
I
P
O
= Output
OD
= Open-Drain (no P diode to VDD)
Note 1: Alternate assignment for ECCP2/P2A in PIC18F8525/8621 devices when CCP2MX (CONFIG3H<0>) is not set (all
Program Memory modes except Microcontroller).
2: Default assignment for ECCP2/P2A when CCP2MX is set (all devices).
3: External memory interface functions are only available on PIC18F8525/8621 devices.
4: Default assignment for P1B/P1C/P3B/P3C for PIC18F8525/8621 devices when ECCPMX (CONFIG3H<1>) is set and for
all PIC18F6525/6621 devices.
5: Alternate assignment for ECCP2/P2A in PIC18F8525/8621 devices when CCP2MX is not set (Microcontroller mode).
6: PORTH and PORTJ (and their multiplexed functions) are only available on PIC18F8525/8621 devices.
7: Alternate assignment for P1B/P1C/P3B/P3C for PIC18F8525/8621 devices when ECCPMX (CONFIG3H<1>) is not set.
8: AVDD must be connected to a positive supply and AVSS must be connected to a ground reference for proper operation of
the part in user or ICSP™ modes. See parameter D001 for details.
9: RG5 is multiplexed with MCLR and is only available when the MCLR Resets are disabled.
DS39612B-page 16
