PIC17C75X
20.3
DC CHARACTERISTICS:
PIC17C752/756-25
(Commercial, Industrial)
PIC17C752/756-33 (Commercial, Industrial)
PIC17LC752/756-08 (Commercial, Industrial)
Standard Operating Conditions (unless otherwise stated)
Operating temperature
DC CHARACTERISTICS
Param.
-40˚C ≤ TA ≤ +85˚C for industrial and
0˚C ≤ TA ≤ +70˚C for commercial
Operating voltage VDD range as described in Section 20.1
No.
Sym
Characteristic
Input Low Voltage
I/O ports
with TTL buffer (Note 6)
Min
Typ†
Max Units
Conditions
VIL
D030
VSS
VSS
–
–
0.8
V
V
4.5V ≤ VDD ≤ 5.5V
3.0V ≤ VDD ≤ 4.5V, and
5.5V ≤ VDD ≤ 6.0V
0.2VDD
D031
D032
with Schmitt Trigger buffer
VSS
Vss
–
–
0.2VDD
0.2VDD
V
V
MCLR, OSC1 (in EC and RC
mode)
Note1
D033
OSC1 (in XT, and LF mode)
Input High Voltage
I/O ports
–
0.5VDD
–
V
VIH
D040
D041
with TTL buffer (Note 6)
2.0
1 + 0.2VDD
–
–
VDD
VDD
V
V
4.5V ≤ VDD ≤ 5.5V
3.0V ≤ VDD ≤ 4.5V, and
5.5V ≤ VDD ≤ 6.0V
with Schmitt Trigger buffer
0.8VDD
–
VDD
V
D042
D043
D050
MCLR
OSC1 (XT, and LF mode)
VHYS Hysteresis of
Schmitt Trigger inputs
0.8VDD
–
0.15VDD *
–
0.5VDD
–
VDD
–
–
V
V
V
Note1
Input Leakage Current
(Notes 2, 3)
D060
IIL
I/O ports (except RA2, RA3)
–
–
±1
µA Vss ≤ VPIN ≤ VDD,
I/O Pin (in digital mode) at
hi-impedance PORTB weak
pull-ups disabled
D061
D062
D063
D063B
MCLR, TEST
RA2, RA3
OSC1 (EC, RC modes)
OSC1 (XT, LF modes)
–
–
±2
±2
±1
µA VPIN = Vss or VPIN = VDD
µA Vss ≤ VRA2, VRA3 ≤ 12V
µA Vss ≤ VPIN ≤ VDD
–
–
–
–
VPIN
µA RF ≥ 1 MΩ, see Figure 4-2
D064
MCLR, TEST
–
–
25
µA VMCLR = VPP = 12V
(when not programming)
D070
IPURB PORTB weak pull-up current
60
200
400
µA VPIN = VSS, RBPU = 0
4.5V ≤ VDD ≤ 6.0V
*
These parameters are characterized but not tested.
†
Data in “Typ” column is at 5V, 25°C unless otherwise stated.These parameters are for design guidance only
and are not tested.
‡
These parameters are for design guidance only and are not tested, nor characterized.
Note 1: In RC oscillator configuration, the OSC1/CLKIN pin is a Schmitt Trigger input. It is not recommended that the
PIC17CXXX devices be driven with external clock in RC mode.
2: The leakage current on the MCLR pin is strongly dependent on the applied voltage level. The specified levels
represent normal operating conditions. Higher leakage current may be measured at different input voltages.
3: Negative current is defined as coming out of the pin.
4: These specifications are for the programming of the on-chip program memory EPROM through the use of the
table write instructions. The complete programming specifications can be found in: PIC17C75X Programming
Specifications (Literature number DS TBD).
5: The MCLR/VPP pin may be kept in this range at times other than programming, but is not recommended.
6: For TTL buffers, the better of the two specifications may be used.
1997 Microchip Technology Inc.
Preliminary
DS30264A-page 227
