PIC17C75X
TABLE 20-1: CROSS REFERENCE OF DEVICE SPECS FOR OSCILLATOR CONFIGURATIONS
AND FREQUENCIES OF OPERATION (COMMERCIAL DEVICES)
JW Devices
(Ceramic Windowed
Devices)
PIC17LC752-08
PIC17LC756-08
PIC17C752-25
PIC17C756-25
PIC17C752-33
PIC17C756-33
OSC
RC VDD: 3.0V to 6.0V
IDD †: 6 mA max.
VDD: 4.5V to 6.0V
IDD †: 6 mA max.
VDD: 4.5V to 6.0V
IDD †: 6 mA max.
VDD: 4.5V to 6.0V
IDD †: 6 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 4 MHz max.
IPD †: 5 µA max. at 5.5V
Freq: 4 MHz max.
IPD †: 5 µA max. at 5.5V
Freq: 4 MHz max.
IPD †: 5 µA max. at 5.5V
Freq: 4 MHz max.
XT VDD: 3.0V to 6.0V
IDD †: 12 mA max.
VDD: 4.5V to 6.0V
IDD †: 38 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 25 MHz max.
VDD: 4.5V to 6.0V
IDD †: 50 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 33 MHz max.
VDD: 4.5V to 6.0V
IDD †: 50 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 33 MHz max.
IPD †: 5 µA max. at 5.5V
Freq: 8 MHz max.
EC VDD: 3.0V to 6.0V
IDD †: 12 mA max.
VDD: 4.5V to 6.0V
IDD †: 38 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 25 MHz max.
VDD: 4.5V to 6.0V
IDD †: 50 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 33 MHz max.
VDD: 4.5V to 6.0V
IDD †: 50 mA max.
IPD †: 5 µA max. at 5.5V
Freq: 33 MHz max.
IPD †: 5 µA max. at 5.5V
Freq: 8 MHz max.
LF VDD: 3.0V to 6.0V
VDD: 4.5V to 6.0V
VDD: 4.5V to 6.0V
VDD: 3.0V to 6.0V
IDD †: 115 µA max. at 32 kHz IDD †: 85 µA typ. at 32 kHz
IDD †: 85 µA typ. at 32 kHz
IPD †: < 1 µA typ. at 5.5V
Freq: 2 MHz max.
IDD †: 115 µA max. at 32 kHz
IPD †: 5 µA max. at 5.5V
Freq: 2 MHz max.
IPD †: 5 µA max. at 5.5V
IPD †: < 1 µA typ. at 5.5V
Freq: 2 MHz max.
Freq: 2 MHz max.
The shaded sections indicate oscillator selections which are tested for functionality, but not for MIN/MAX specifications.
It is recommended that the user select the device type that ensures the specifications required.
†
The WDT, BOR,and A/D circuitry are disabled.
