PIC16F/LF1946/47
29.4 DC Characteristics: PIC16F/LF1946/47-I/E (Continued)
Standard Operating Conditions (unless otherwise stated)
DC CHARACTERISTICS
Operating temperature -40°C TA +85°C for industrial
-40°C TA +125°C for extended
Param
No.
Sym.
Characteristic
Min.
Typ†
Max.
Units
Conditions
Capacitive Loading Specs on Output Pins
D101*
COSC2 OSC2 pin
—
—
—
15
pF
In XT, HS and LP modes when
external clock is used to drive
OSC1
D101A* CIO
All I/O pins
—
50
pF
VCAP Capacitor Charging
Charging current
D102
—
—
200
0.0
—
—
A
mA
D102A
Source/sink capability when
charging complete
Legend:
TBD = To Be Determined
These parameters are characterized but not tested.
*
†
Data in “Typ” column is at 3.0V, 25°C unless otherwise stated. These parameters are for design guidance only and are
not tested.
Note 1: In RC oscillator configuration, the OSC1/CLKIN pin is a Schmitt Trigger input. It is not recommended to use an external
clock in RC mode.
2: Negative current is defined as current sourced by the pin.
3: The leakage current on the MCLR pin is strongly dependent on the applied voltage level. The specified levels represent
normal operating conditions. Higher leakage current may be measured at different input voltages.
4: Including OSC2 in CLKOUT mode.
DS41414A-page 392
Preliminary
2010 Microchip Technology Inc.
