PIC16F/LF1946/47
29.0 ELECTRICAL SPECIFICATIONS
(†)
Absolute Maximum Ratings
Ambient temperature under bias....................................................................................................... -40°C to +125°C
Storage temperature ........................................................................................................................ -65°C to +150°C
Voltage on VDD with respect to VSS ................................................................................................... -0.3V to +6.5V
Voltage on VCAP pin with respect to VSS.............................................................................................. -0.3V to +4.0V
Voltage on VDD with respect to VSS ................................................................................................... -0.3V to +4.0V
Voltage on MCLR with respect to Vss ................................................................................................. -0.3V to +9.0V
Voltage on all other pins with respect to VSS ........................................................................... -0.3V to (VDD + 0.3V)
Total power dissipation(1) ...............................................................................................................................800 mW
Maximum current out of VSS pin, -40°C TA +85°C for industrial............................................................... 425 mA
Maximum current out of VSS pin, -40°C TA +125°C for extended ............................................................ 175 mA
Maximum current into VDD pin, -40°C TA +85°C for industrial.................................................................. 425 mA
Maximum current into VDD pin, -40°C TA +125°C for extended............................................................... 175 mA
Clamp current, IK (VPIN < 0 or VPIN > VDD)20 mA
Maximum output current sunk by any I/O pin....................................................................................................25 mA
Maximum output current sourced by any I/O pin .............................................................................................. 25 mA
Note 1: Power dissipation is calculated as follows: PDIS = VDD x {IDD – IOH} + {(VDD – VOH) x IOH} + (VOl x IOL).
† NOTICE: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent damage to the
device. This is a stress rating only and functional operation of the device at those or any other conditions above those
indicated in the operation listings of this specification is not implied. Exposure above maximum rating conditions for
extended periods may affect device reliability.
2010 Microchip Technology Inc.
Preliminary
DS41414A-page 381
