PIC16F/LF1946/47
REGISTER 22-6: PSTRxCON: PWM STEERING CONTROL REGISTER(1)
U-0
—
U-0
—
U-0
—
R/W-0/0
R/W-0/0
STRxD
R/W-0/0
STRxC
R/W-0/0
STRxB
R/W-1/1
STRxA
STRxSYNC
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
x = Bit is unknown
‘0’ = Bit is cleared
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
u = Bit is unchanged
‘1’ = Bit is set
bit 7-5
bit 4
Unimplemented: Read as ‘0’
STRxSYNC: Steering Sync bit
1= Output steering update occurs on next PWM period
0= Output steering update occurs at the beginning of the instruction cycle boundary
bit 3
bit 2
bit 1
bit 0
STRxD: Steering Enable bit D
1= PxD pin has the PWM waveform with polarity control from CCPxM<1:0>
0= PxD pin is assigned to port pin
STRxC: Steering Enable bit C
1= PxC pin has the PWM waveform with polarity control from CCPxM<1:0>
0= PxC pin is assigned to port pin
STRxB: Steering Enable bit B
1= PxB pin has the PWM waveform with polarity control from CCPxM<1:0>
0 = PxB pin is assigned to port pin
STRxA: Steering Enable bit A
1= PxA pin has the PWM waveform with polarity control from CCPxM<1:0>
0= PxA pin is assigned to port pin
Note 1: The PWM Steering mode is available only when the CCPxCON register bits CCPxM<3:2> = 11and
PxM<1:0> = 00.
DS41414A-page 234
Preliminary
2010 Microchip Technology Inc.
