PIC16F/LF1946/47
22.4.2
FULL-BRIDGE MODE
In Full-Bridge mode, all four pins are used as outputs.
An example of Full-Bridge application is shown in
Figure 22-10.
In the Forward mode, pin CCPx/PxA is driven to its active
state, pin PxD is modulated, while PxB and PxC will be
driven to their inactive state as shown in Figure 22-11.
In the Reverse mode, PxC is driven to its active state, pin
PxB is modulated, while PxA and PxD will be driven to
their inactive state as shown Figure 22-11.
PxA, PxB, PxC and PxD outputs are multiplexed with
the PORT data latches. The associated TRIS bits must
be cleared to configure the PxA, PxB, PxC and PxD
pins as outputs.
FIGURE 22-10:
EXAMPLE OF FULL-BRIDGE APPLICATION
V+
QC
QA
FET
Driver
FET
Driver
PxA
PxB
Load
FET
Driver
FET
Driver
PxC
PxD
QD
QB
V-
DS41414A-page 220
Preliminary
2010 Microchip Technology Inc.
