PACKAGING INFORMATION
Package Marking Information
Example:
5-Lead SOT-23 (MCP6271 and MCP6271R)
Device
Code
MCP6271
CGNN
ETNN
XXNN
CG25
MCP6271R
Note: Applies to 5-Lead SOT-23
Example:
6-Lead SOT-23 (MCP6273)
XXNN
CK25
8-Lead MSOP
Example:
XXXXXX
YWWNNN
6271E
644256
8-Lead PDIP (300 mil)
Example:
XXXXXXXX
XXXXXNNN
MCP6271
E/P256
0437
MCP6271
E/P^ 256
0644
e3
^
OR
YYWW
8-Lead SOIC (150 mil)
Example:
XXXXXXXX
XXXXYYWW
MCP6271
E/SN0437
MCP6271E
e
3
SN^^0644
OR
NNN
256
256
Legend: XX...X Customer-specific information
Y
YY
Year code (last digit of calendar year)
Year code (last 2 digits of calendar year)
WW
NNN
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code
Pb-free JEDEC designator for Matte Tin (Sn)
e
3
*
This package is Pb-free. The Pb-free JEDEC designator (
can be found on the outer packaging for this package.
)
e3
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
