MCP6141/2/3/4
6.0
6.1
PACKAGING INFORMATION
Package Marking Information
Example:
5-Lead SOT-23 (MCP6141)
Device
E-Temp Code
MCP6141
ASNN
XXNN
AS25
Note: Applies to 5-Lead SOT-23
Example:
6-Lead SOT-23 (MCP6143)
Device
MCP6143
E-Temp Code
AWNN
XXNN
AW25
Note: Applies to 6-Lead SOT-23
Example:
8-Lead MSOP
XXXXXX
6143I
YWWNNN
536256
Legend: XX...X Customer-specific information
Y
YY
Year code (last digit of calendar year)
Year code (last 2 digits of calendar year)
WW
NNN
Week code (week of January 1 is week ‘01’)
Alphanumeric traceability code
e
3
Pb-free JEDEC designator for Matte Tin (Sn)
This package is Pb-free. The Pb-free JEDEC designator (
can be found on the outer packaging for this package.
*
)
3
e
Note: In the event the full Microchip part number cannot be marked on one line, it will
be carried over to the next line, thus limiting the number of available
characters for customer-specific information.
© 2005 Microchip Technology Inc.
DS21668B-page 17
