MCP2515
REGISTER 4-10: RXFnSIDH – FILTER n STANDARD IDENTIFIER HIGH
(ADDRESS: 00h, 04h, 08h, 10h, 14h, 18h)
R/W-x
SID10
R/W-x
SID9
R/W-x
SID8
R/W-x
SID7
R/W-x
SID6
R/W-x
SID5
R/W-x
SID4
R/W-x
SID3
bit 7
bit 0
bit 7-0
SID: Standard Identifier Filter bits <10:3>
These bits hold the filter bits to be applied to bits <10:3> of the Standard Identifier portion of a
received message
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
‘1’ = Bit is set
REGISTER 4-11: RXFnSIDL – FILTER n STANDARD IDENTIFIER LOW
(ADDRESS: 01h, 05h, 09h, 11h, 15h, 19h)
R/W-x
SID2
R/W-x
SID1
R/W-x
SID0
U-0
—
R/W-x
EXIDE
U-0
—
R/W-x
EID17
R/W-x
EID16
bit 7
bit 0
bit 7-5
SID: Standard Identifier Filter bits <2:0>
These bits hold the filter bits to be applied to bits <2:0> of the Standard Identifier portion of a
received message
bit 4
bit 3
Unimplemented: Reads as ‘0’
EXIDE: Extended Identifier Enable bit
1= Filter is applied only to Extended Frames
0= Filter is applied only to Standard Frames
bit 2
Unimplemented: Reads as ‘0’
bit 1-0
EID: Extended Identifier Filter bits <17:16>
These bits hold the filter bits to be applied to bits <17:16> of the Extended Identifier portion of
a received message
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
‘1’ = Bit is set
