KSZ8795CLX
TABLE 4-21: ACL INDIRECT REGISTERS FOR 14 BYTE ACL RULES (CONTINUED)
Address
Name
Description
Mode
Default
Port_ACL_3
ACL Port Register 3 (0x03)
Reg. 110 (0x6E) Bits[7:5] = 010 for ACL, Reg. 110 Bits[3:0] = 0xn for Ports 1, 2, 3, 4, and 5.
Reg. 111 (0x6F) Bits[7:0] = Offset 0x03 to access the Indirect Byte Register 0xA0.
Location: (010 ACL) -> {0xn, offset} -> 0xA0 holds the data.
Matching Fields for Layer 2
7 - 0
MAC_ADDR MAC Address
[39:32]
R/W
00000000
Port_ACL_4
ACL Port Register 4 (0x04)
Reg. 110 (0x6E) Bits[7:5] = 010 for ACL, Reg. 110 Bits[3:0] = 0xn for Ports 1, 2, 3, 4, and 5.
Reg. 111 (0x6F) Bits[7:0] = Offset 0x04 to access the Indirect Byte Register 0xA0.
Location: (010 ACL) -> {0xn, offset} -> 0xA0 holds the data.
Matching Fields for Layer 2
7 - 0
MAC_ADDR MAC Address
[31:24]
R/W
00000000
00000000
00000000
00000000
00000000
Port_ACL_5
ACL Port Register 5 (0x05)
Reg. 110 (0x6E) Bits[7:5] = 010 for ACL, Reg. 110 Bits[3:0] = 0xn for Ports 1, 2, 3, 4, and 5.
Reg. 111 (0x6F) Bits[7:0] = Offset 0x05 to access the Indirect Byte Register 0xA0.
Location: (010 ACL) -> {0xn, offset} -> 0xA0 holds the data.
Matching Fields for Layer 2
7 - 0
MAC_ADDR MAC Address
[23:16]
R/W
Port_ACL_6
ACL Port Register 6 (0x06)
Reg. 110 (0x6E) Bits[7:5] = 010 for ACL, Reg. 110 Bits[3:0] = 0xn for Ports 1, 2, 3, 4, and 5.
Reg. 111 (0x6F) Bits[7:0] = Offset 0x06 to access the Indirect Byte Register 0xA0.
Location: (010 ACL) -> {0xn, offset} -> 0xA0 holds the data.
Matching Fields for Layer 2
7 - 0
MAC_ADDR MAC Address
[15:8]
R/W
Port_ACL_7
ACL Port Register 7 (0x07)
Reg. 110 (0x6E) Bits[7:5] = 010 for ACL, Reg. 110 Bits[3:0] = 0xn for Ports 1, 2, 3, 4, and 5.
Reg. 111 (0x6F) Bits[7:0] = Offset 0x07 to access the Indirect Byte Register 0xA0.
Location: (010 ACL) -> {0xn, offset} -> 0xA0 holds the data.
Matching Fields for Layer 2
7 - 0
MAC_ADDR MAC Address
[7:0]
R/W
Port_ACL_8
ACL Port Register 8 (0x08)
Reg. 110 (0x6E) Bits[7:5] = 010 for ACL, Reg. 110 Bits[3:0] = 0xn for Ports 1, 2, 3, 4, and 5.
Reg. 111 (0x6F) Bits[7:0] = Offset 0x08 to access the Indirect Byte Register 0xA0.
Location: (010 ACL) -> {0xn, offset} -> 0xA0 holds the data.
Matching Fields for Layer 2
7 - 0
TYPE[15:8] Ether Type
R/W
2016 Microchip Technology Inc.
DS00002112A-page 89
