MX25L12835F
Table 12. Parameter Table (1): Macronix Flash Parameter Tables
Add (h) DW Add
Data
Data
(h)
Description
Comment
2000h=2.000V
2700h=2.700V
3600h=3.600V
(Byte)
(Bit)
(h/b) note1
07:00
15:08
00h
36h
00h
36h
Vcc Supply Maximum Voltage
61h:60h
1650h=1.650V
2250h=2.250V
2350h=2.350V
2700h=2.700V
23:16
31:24
00h
27h
00h
27h
Vcc Supply Minimum Voltage
H/W Reset# pin
63h:62h
0=not support 1=support
00
1b
H/W Hold# pin
0=not support 1=support
0=not support 1=support
0=not support 1=support
01
02
03
0b
1b
1b
Deep Power Down Mode
S/W Reset
Reset Enable (66h) should be issued
before Reset Opcode
1001 1001b
(99h)
65h:64h
F99Dh
S/W Reset Opcode
11:04
Program Suspend/Resume
Erase Suspend/Resume
Unused
0=not support 1=support
0=not support 1=support
12
13
1b
1b
14
1b
Wrap-Around Read mode
Wrap-Around Read mode Opcode
0=not support 1=support
15
1b
66h
67h
23:16
C0h
C0h
64h
08h:support 8B wrap-around read
16h:8B&16B
32h:8B&16B&32B
Wrap-Around Read data length
31:24
64h
64h:8B&16B&32B&64B
Individual block lock
0=not support 1=support
00
01
1b
0b
Individual block lock bit
(Volatile/Nonvolatile)
0=Volatile 1=Nonvolatile
1110 0001b
(E1h)
Individual block lock Opcode
09:02
10
Individual block lock Volatile
protect bit default protect status
0=protect 1=unprotect
0b
CB85h
6Bh:68h
Secured OTP
Read Lock
Permanent Lock
Unused
0=not support 1=support
0=not support 1=support
0=not support 1=support
11
12
1b
0b
13
0b
15:14
31:16
11b
FFh
FFh
Unused
FFh
FFh
Unused
6Fh:6Ch [31:00]
P/N: PM1795
REV. 1.0, OCT. 23, 2012
