MX25L12835F
Figure 63. Read SPB Status (RDSPB) Sequence
CS#
0
1
2
3
4
5
6
7
8
9
37 38 39 40 41 42 43 44 45 46 47
Mode 3
Mode 0
SCLK
Command
E2h
32-Bit Address
(Note)
A31 A30
A2 A1 A0
SI
MSB
Data Out
High-Z
SO
7
6
5
4
3
2
1
0
MSB
Note: One dummy byte follow 3-byte address.
Figure 64. SPB Erase (ESSPB) Sequence
CS#
0
1
2
3
4
5
6
7
Mode 3
SCLK
Mode 0
Command
E4h
SI
High-Z
SO
Figure 65. SPB Program (WRSPB) Sequence
CS#
0
1
2
3
4
5
6
7
8
9
37 38 39
Mode 3
Mode 0
SCLK
Command
E3h
32-Bit Address
(Note)
A31 A30
A2 A1 A0
SI
MSB
Note: One dummy byte follow 3-byte address.
P/N: PM1795
REV. 1.0, OCT. 23, 2012
69
