MX25L12835F
Figure 21. Program/Erase flow without read array data (read P_FAIL/E_FAIL flag)
start
WREN command
RDSR command*
No
WEL=1?
Yes
Program/erase command
Write program data/address
(Write erase address)
RDSR command
No
WIP=0?
Yes
RDSR command
Read WEL=0, BP[3:0], QE,
and SRWD data
RDSCUR command
P_FAIL/E_FAIL =1 ?
Yes
No
Program/erase successfully
Program/erase fail
Yes
Program/erase
another block?
* Issue RDSR to check BP[3:0].
* If WPSEL = 1, issue RDSPB and RDDPB to check the block status.
No
Program/erase completed
P/N: PM1795
REV. 1.0, OCT. 23, 2012
