In the idle state, both transmitters are disabled, while all
Doubly Isolated RS-485 Repeater
The RS-422/RS-485 standard is specified for cable
lengths up to 4000 feet. When approaching or exceed-
ing the specified maximum cable length, a ground-
potential difference of several tens of volts can easily
develop. This difference can be either DC, AC, at
power-line frequency, or any imaginable noise or
impulse waveform. It is typically very low impedance so
that if a connection between the two grounds is
attempted, very large currents may flow. These cur-
rents are by their nature unstable and unpredictable. In
addition, they may cause noise to be injected into sen-
sitive instrumentation and, in severe cases, might actu-
ally cause physical damage to such equipment.
receivers in the system are enabled. If any device on
the system has information for any other device, it starts
sending its data onto the bus. Each data transmission
on the bus retriggers the one-shot, keeping the sending
transmitter enabled until there are no more transmis-
sions. All receivers receive all data; if this is undesir-
able, the protocol must allow for an address field so
receivers can ignore data not directed to them.
Each node must refrain from transmitting when data
already exists on the bus, and must resend data that is
corrupted by the collisions that inevitably occur with a
party-line system. With the repeater of Figure 15, there
might be transmitters up to 8000 feet apart. That repre-
sents more than 8µs (assuming 1ns/foot of delay) in
which two nodes could be transmitting simultaneously.
Figure 15 shows a half-duplex (two-wire), bidirectional,
party-line repeater system that prevents interference
and/or damage from ground-potential differences. Two
MAX1480A/MAX1480B/MAX1480C isolated RS-485
transceivers are used to isolate each of the network
segments from the electrical environment of the
repeater. The MAX1480A/MAX1480B/MAX1480C also
regenerate bus signals that may have been degraded
by line attenuation or dispersion.
The circuit in Figure 15 can be used either directly as
shown, with the slew-rate-limited MAX1480B/
MAX1480C, for data transfer rates up to 250kbps, or
with the MAX1480A for data rates up to 2.5Mbps (see
Table 1 for pullup and LED resistor values when using
the MAX1480A or MAX1480B). If dual-port isolation is
not needed, one of the MAX1480C devices can be
replaced by a MAX487 for 250kbps applications.
