88E1111 Product Brief
Integrated 10/100/1000 Ultra Gigabit Ethernet Transceiver
Table 3:
TBI Interface (Continued)
117-TFBGA 96-BCC 128-PQFP Pin Name
Pin
Description
Pin #
Pin #
Pin #
Type
D2
3
8
RX_ER/
RXD9
O, Z
TBI Receive Data code group bit 9. In the
TBI mode, RX_ER is used as RXD9.
RXD[9:0] are synchronous to RCLK0 and
RCLK1.
B5
B6
84
83
115
114
CRS/
COMMA
O, Z
I
TBI Valid Comma Detect. In the TBI mode,
CRS is used as COMMA.
COL/LPBK
TBI Mode Loopback. In the TBI mode, COL
is used to indicate loopback on the TBI.
When a “0 - 1" transition is sampled on this
pin, bit 0.14 is set to 1.
When a “1 - 0" is sampled on this pin, bit
0.14 is reset to 0.
If this feature is not used, the COL pin
should be driven low on the board. This pin
should not be left floating in TBI mode.
Doc. No. MV-S105540-00, Rev. --
Page 16
Copyright © 2009 Marvell
Document Classification: Proprietary Information
March 4, 2009, Advance
