Ribbon Cable Interconnect Solutions
System 50 Cable-to-Board Connectors,
.025 [0.64] Centerline Ribbon Cable
(Continued)
Double Row Receptacle
.254 .228
[6.45] [5.79]
.025
[0.64]
Centerline Ribbon Cable Connectors
System 50 Cable-to-Board Connectors
A
.054
[1.37]
B
C
Cover
Latch
.580
[14.73]
Before
Termination
Material and Finish
Housing
— Black thermoplastic,
UL 94V-0 rated
Latches
— Stainless steel
Contacts
— Phosphor bronze, plated
30 microinch gold over nickel with tin
in termination area
.430
[10.92]
.198
[5.03]
.228
[5.80]
.246
[6.25]
.335
[8.51]
Contact
.100
[2.54]
Housing
Position #1
Indicator
F
.102
[2.59]
E
Related Product Data
Mateable Connectors
—
See AMP Catalog 82178
See Part Numbers 104068 and 104069
Series on pages 10 and 11
Mates with Posts
— .015 [0.38]
square, .125 [3.18] long, on
.050 x .100 [1.27 x 2.54] grid
.100
[2.54]
D
.050
Typ.
[1.27]
No. of
Pos.
10
14
16
20
24
26
30
34
40
44
50
60
64
68
72
80
100
Technical Documents
Product Specification
108-1109
Application Specification
114-25029
A
.510
12.95
.610
15.49
.660
16.76
.760
19.30
.860
20.32
.910
23.11
1.010
25.65
1.110
28.19
1.260
32.00
1.360
34.54
1.510
38.35
1.760
44.70
1.860
47.24
1.960
49.78
2.060
52.32
2.260
57.40
2.760
70.10
B
.445
11.30
.545
13.84
.595
15.11
.695
17.65
.795
20.19
.845
21.46
.945
24.00
1.045
26.54
1.195
30.35
1.295
32.89
1.445
36.70
1.695
43.05
1.795
45.59
1.895
48.13
1.995
50.67
2.195
55.75
2.695
68.45
Dimensions
C
D
.225
.200
5.72
5.08
.325
.300
8.26
7.62
.375
.350
9.52
8.89
.475
.450
12.07
11.43
.575
.550
14.61
13.97
.625
.600
15.88
15.24
.725
.700
18.42
17.78
.825
.800
20.96
20.32
.975
.950
34.54
24.13
1.075
1.050
27.31
26.67
1.225
1.200
31.12
30.48
1.475
1.450
37.47
36.83
1.575
1.550
40.00
39.37
1.675
1.650
42.55
41.91
1.775
1.750
45.08
44.45
1.975
1.950
50.17
49.53
2.475
2.450
62.87
62.23
E
.096
2.44
.146
3.71
.171
4.34
.221
5.61
.271
6.88
.296
7.52
.346
8.79
.396
10.06
.471
11.96
.521
13.23
.596
15.14
.721
18.31
.771
19.58
.821
20.85
.871
22.12
.971
24.66
1.221
31.01
F
.294
7.47
.394
10.01
.444
11.28
.544
13.82
.644
16.36
.694
17.63
.794
20.17
.894
22.71
1.044
26.52
1.144
29.06
1.294
32.87
1.544
39.22
1.644
41.76
1.744
44.30
1.844
46.84
2.044
51.92
2.544
64.62
Part Number
2-111196-5
2-111196-6
2-111196-7
1-111196-8
2-111196-8
2-111196-9
1-111196-9
3-111196-0
2-111196-0
3-111196-1
2-111196-1
2-111196-2
3-111196-2
3-111196-4
2-111196-3
3-111196-3
2-111196-4
See Application Specification for termination tooling.
Note:
All part numbers are RoHS compliant.
