AMPLIMITE Subminiature D Connectors
Shielded AMPLIMITE .050 Series Slimline Connectors (Continued)
Shielded Right-Angle
Stacked Header,
Receptacle
Shield
Date Code Marked
In Area Indicated
.168
[4.27]
.215
[5.46]
2 Plc.
.015
.870
[22.10
0.38
]
.803
[20.40]
Position 1
With Shielding
Position 1
.635
[16.13]
Position 26
1.230
[31.24]
Position 26
Without Shielding
.363
[9.22]
.538
[13.67]
.050
[1.27]
Typ.
Material and Finish:
Housing—UL 94V-0 rated thermo-
plastic, black
Bracket—Zinc, plated tin over copper
Metal-Shell—Carbon steel, plated tin
.050
Typ.
.188
[4.76]
over copper
[1.27]
.600
[15.24]
Boardlocks—Copper alloy, tin plated
Contact Shield—Phosphor bronze,
plated tin
Shielded Header with Rear Contact Shield
Part Numbers
Contacts—Phosphor bronze, duplex
plated .000030 [0.00076] min. on
mating end, tin plated on solder end, all
over nickel
No. of
Positions
Std. Rcpt. without
Rcpt. with
Rear Contact Shield3
Keyed1 Unkeyed2
Rear Contact Shield
Keyed1
Unkeyed2
26/26
—
5786200-1
5750821-1 5750820-1
1Lower header unkeyed with 4-40 threaded holes, upper header keyed in keying
position 1. See page 33 for keying code.
2Both headers unkeyed with 4-40 threaded holes.
3Receptacle includes a metal contact shield for added RFI protection to the rear
of the receptacle assembly.
Note: See Application Specification 114-40036 for the most up-to-date detailed panel cutout and recom-
mended PC Board hole pattern.
Note: All part numbers are RoHS compliant.
32
Catalog 82068
Revised 1-08
Dimensions are in inches and
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
