AMPLIMITE .050 Series Application Tooling, Series III
Discrete Wire
Application Tooling
To meet medium to high
volume production of
dis-crete wire terminations,
Tyco Electronics offers the
following tooling:
The CHAMPOMATOR
Model 2.5 Bench
Terminating Machine—
Part No. 354786-1, used in
conjunction with Control
Module—Part No. 852423- ,
▫
and Tie Bar—Part No.
Control Module
Part No. 852423-1 120 VAC
852423-2 100 VAC
CHAMPOMATOR
2.5 Machine Tool Kit
Part No. 354786-1
762637- (Table No. 1).
▫
852423-3 230 VAC
Note: The CHAMPOMATOR 2.5 Machine includes plug
and receptacle nests, as well as wire setup gauge.
Table Number 1
Connector
Size
Tie Bar
Part No.
20 Pos.
26 Pos.
28 Pos.
40 Pos.
50 Pos.
60 Pos.
68 Pos.
80 Pos.
100 Pos.
120 Pos.
1-762637-1
1-762637-1
1-762637-2
1-762637-3
1-762637-4
1-762637-5
1-762637-6
1-762637-7
1-762637-9
1-762637-0
Discrete Wire
Application Tooling
For low to medium volume
production use the AMP
Arbor Frame Assembly—
Part No. 58024-1 equipped
with Applicator—Part No.
91291-1 for .032-.035
[0.81-0.89] Conductor
Insulation O.D. and Appli-
cator—Part No. 91291-2
for .029-.032 [0.74-0.81]
Conductor Insulation O.D.
Note: AMP Arbor Frame Assembly and
Applicator Kit must be ordered separately.
Arbor Frame
Part No. 58024-1
Equipped with
Applicator Part No.
91291-
▫
Note: All part numbers are RoHS compliant.
