AMPLIMITE Subminiature D Connectors
Shielded AMPLIMITE .050 Series Slimline Connectors (Continued)
Cable Connector, Plug
Part No. 750833-1
Material and Finish:
.275
[6.99]
Housing and Termination Covers—
UL 94V-0 rated thermoplastic, black
Shell—Steel, plated bright tin over
copper
.576
[14.63]
Contacts—Phosphor bronze, duplex
plated .000030 [0.00076] min. gold on
mating end, bright tin on termination
end, all underplated nickel
.975
[24.77]
1.170
[29.72]
Bracket—Zinc, plated nickel over
copper
Recommended Wire Size—28 AWG
[0.08 mm2] with max. O.D. .032 [0.813].
PVC or polyolefin insulation.
Note: Cable Connectors must be used with Backshell Kits. See page 34.
Keying Code, Receptacle
Keying Code, Plug
Position 1 (Up)
#2-56 Thread
Accessories
.170
[4.32]
Female Screwlock Kit
.142
[3.61]
Material—Stainless Steel
.170
[4.32]
Note: Female screwlocks to be used with con-
nectors mounted to panels having a thickness
of .047 [1.19]
.390
[9.91]
#4-40 Thread
Part No.
Packaging
Individually Packed Kit
(2 Screwlocks per kit)
750831-1
*Minimum order is 510 kits.
Note: All part numbers are RoHS compliant.
33
Catalog 82068
Revised 1-08
Dimensions are in inches and
Dimensions are shown for
