NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Fastening Hardware (Continued)
For Housings with
Single Mounting Hole
Locking Springs
Material and Finish
.375
[9.53]
Male (Spring Member) -
Spring steel, nickel plated
A Max.
(Assembled)
Female (Latching Member) -
Stainless steel
Male
.375
[9.53]
Locking Springs are used
to hold mated connectors
together. Although Locking
Springs can be used on con-
nectors up to 50 positions,
they are primarily used on
smaller size connectors (less
than 34 positions).
.620
[15.75]
Female
In all applications, a Male
(Spring Member) is used
opposite a Female (Latching
Member). They can be secured
to a connector housing using
Guide Pins and Sockets or
4-40 x .250 [6.35] fillister
head screws and nuts. Locking
Springs can be used with all
hardware, except Closed-End
Pin Hoods.
A Max.
(Assembled)
.320
[8.13]
.375
[9.53]
For Housings with
Three Mounting Holes
A Max.
(Assembled)
Male
.375
[9.53]
.620
[15.75]
Standard
A
Connector
Max.
Size*
1.413
Female
6
35.89
A Max.
(Assembled)
1.662
42.21
14
1.975
50.17
20
.320
[8.13]
2.037
51.74
26
2.412
61.26
34
3.047
77.39
41
Connectors Used On (No. of Positions)
Locking Spring Part No.
3.006
50
Special Application
76.35
Male
(Spring
Member)
Female
(Latching
Member)
Standard
Posted
High
High
*A dimension also applies to
other comparably sized con-
nector types listed in the chart
at the right.
Mixed
Current
Voltage
6, 14, 20
and 41
6, 14, 20
and 41
201921-1
201922-1
—
—
—
201923-1
201925-1
201918-1*
201926-1
26
26
—
—
15
—
34 and 50
34 and 50
16 and 42
20
*Single female latch, two must be ordered per assembly.
