NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Special Application Connectors (Continued)
High Voltage 28
Position UL Voltage
Rating: 1800 V
Material and Finish
Housing - Phenolic, 94V-O
rated, black
Contacts must be ordered
separately.
.500
[12.70]
1.305
[33.15]
.140
[3.56]
.327
.365
[9.27]
[8.31]
.156
Dia.
[3.96]
4 Plc.
.015
[0.38]
Typ.
R
2.281
[47.94]
1.983±.010
[50.37±0.25
2.595±.020
]
2.025
[51.44]
[65.91±0.51
]
.195
[4.95]
.766
.128
[3.25]
.156
1.110±.010
[28.19±0.25
.120
Dia.
[19.46]
Dia.
[3.96]
[3.05]
]
4 Holes
1.155
[29.34]
4 Plc.
Plug Housing
Recommended Panel Cutout
.915
[23.24]
.766
[19.46]
.365
[9.27]
.156
Dia.
[3.96]
4 Holes
1.983±.010
[50.37±0.25
2.595±.020
]
[65.91±0.51
]
1.110±.010
.120
Dia.
[28.19±0.25
]
[3.05]
4 Plc.
Receptacle Housing
Phenolic
Housing Part No.
Contacts Accepted
Quantity
Contact Type
Page Ref.
Plug
Receptacle
Type II
30
Type III+
Subminiature
COAXICON
31-35
205689-2
205690-2
28*
40, 41
*Quantity may be all of the same type, or a combination of those types listed.
Note: 28 Position connector uses Standard 75 Position Hardware. Refer to appropriate column of
Application Charts for Hardware Selection Pages 10 through 25.
76
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
