AMP M Series
Pin and Socket Connectors
Special Application Connectors (Continued)
Mixed 42 Position
Material and Finish
Housing - Phenolic, black or
diallyl phthalate, blue, 94V-O
rated
Contacts must be ordered
separately.
.790
[20.01]
.395
.915
[23.24]
.065
[1.65]
or
[10.03]
R
.750±.010
.365
[9.27]
2 Plc.
[19.05±0.25
]
.161
[4.09]
.109
[2.77] R†
.120
[3.05]
2 Plc.
Dia.
.016
[0.41]
Typ.
R
2.281
[57.94]
2.282
[57.96]
2.593±.020
[65.86±0.51
]
2.025
[51.44]
.130
Dia.
[3.30]
or
.128
.218
[5.54]
4 Plc.
[3.25]
Dia.
.218
[5.54] Dia.†
.120
[3.05]
4 Plc.
Dia.
.468
[11.89]
.130
[3.30]
Dia.
4 Holes
†.218 [5.54] diameter is required
when jackscrews are used.
Recommended Panel Cutout
Plug Housing
Receptacle Housing
Phenolic
Housing Part No.
Diallyl Phthalate
Housing Part No.
Contacts Accepted
Quantity Contact Type Page Ref.
Plug
Receptacle
Plug
Receptacle
Type II
30
Type III+
31-35
36*
6*
Subminiature
COAXICON
40, 41
36
202515-1
202516-1
202515-3
202516-3
Type I
Miniature
COAXICON
42, 43
*Quantity may be all of the same type, or a combination of those types listed.
Note: 42 position connector uses Standard 50 Position Hardware. Refer to appropriate column of
Application Charts for Hardware Selection pages 10 through 25.
