NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Introduction (Continued)
What makes the M Series
connector line so versatile
A - Determine Connector Type–
This decision is based on the
and special for a wide variety selected contact types, circuit
of applications?
density requirements and, if
posted connectors are desired,
in-plant production capabilities
for wiring connectors using
hand tools or semiautomatic
tooling. Detailed specifications
of the various M Series connec-
tors are presented on the
following pages: Standard con-
nectors (pages 44 through 51),
Posted connectors (pages 52
through 60), Special
•ꢀCompatibility–Most
connectors intermateable
with connectors made to
MIL-C-28748 requirements.
•ꢀWide range–Choice of con-
nector styles and sizes:
standard connectors
(unloaded), posted connec-
tors (preloaded) and special
application connectors.
Application connectors (pages
61 through 77).
•ꢀComplete line–Full line of
accessory hardware for fas-
tening, protecting, guiding,
strain relief and keying.
B - Determine Hardware–
This decision is based on the
selected connector types, and
the individual application
requirements for fastening, pro-
tection, shielding, guiding, strain
relief and keying. To assist cus-
tomers in determining the
•ꢀVariety of contacts–Signal,
power, coaxial, and posted
versions—many are inter-
changeable and can be
intermixed in the same con-
nector housing.
proper hardware to use, hard-
ware selection information has
been formulated for each con-
nector type. This information is
located on pages 10 through 25.
Complete specifications of each
hardware component are pre-
sented in the Hard-ware section
of the catalog (pages 78
•ꢀFull complement of applica-
tion tooling–For wire crimp
and posted terminationshand
tools, semiautomatic tooling
and fully automatic machines
provide highly reliable, low
cost terminations to meet
production requirements.
through 89).
How to choose the appropri-
ate connector/contact/
hardware combination
C - Determine Contact Type –
This decision is based on wire
size(s) and reliability and cost
requirements of an application,
as well as the customer’s in-
plant production capabilities.
Complete specifications, includ-
ing accepted wire sizes and
available platings of all pin and
socket contacts, are presented
in the Contacts section of the
catalog (pages 30 through 43).
Application tooling for crimp-
and post-type contacts is
Choosing the appropriate con-
nector/contact/hardware
combination is essential to the
proper function of any
AMP M Series connector. First,
a customer must evaluate
each individual application
with regards to: wire size(s);
number of circuits; available
space; fastening methods; and
needs for protection, shielding,
guiding, strain relief and key-
ing. Then, the customer must
consider the following factors
to make the appropriate selec-
tion of M Series connectors
and related components.
presented on pages 90 and 91).
5
Catalog 82003
Revised 06-08
Dimensions are in millimeters
Dimensions are shown for
USA: 1-800-522-6752
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-141-810-8967
and inches unless otherwise
specified. Values in brackets are
equivalent U.S. Customary Units.
reference purposes only.
Specifications subject
to change.
