NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Coaxial Contacts (Continued)
Selection Chart for Twisted Pair and Shielded Wire
Subminiature, Crimp,
Snap-In, Size 16
(Continued)
Tooling Part No.
Loose Piece
Wire Size
Contact
Finish
Ferrule
Die Inserts for
Contact No.
Hand
Tool
Part No.
Hand Tool 69710-1
AWG [mm2]
Pin
Socket
or Pneumatic Tool*
30
0.05
Gold/Nickel
226537-3 51565-3
1-332057-0
1-332057-0
69690-2
69690
69656-2
69656
(Twisted Pair, Solid) Gold/Copper1
28 0.08-0.09
Gold/Nickel
226537-3 51565-3
226537-3 51565-3
(Twisted Pair, Solid) Gold/Copper1
28 0.08-0.09
69690-1
or
69690-2
354940-1 & 91911-4
(Twisted Pair,
Stranded 7 Str.,
.0050 [0.13] Dia.)
Gold/Nickel 1
Gold/Copper
or
69656-2
1-332057-0
1-332057-0
1-332057-0
26 0.12-0.15
(Twisted Pair, Solid Gold/Nickel1
or Stranded 7 Str. Gold/Copper
.0063 [0.16] Dia.)
226537-3 51565-3
69690
69656
Gold/Nickel
226537-1 51565-1
226537-4 51565-4
26 0.12-0.15
(Shielded, .075 [1.91]
Max. O.D.)
Gold/Copper1
69690-3
69656-3
Gold/Nickel
Gold/Copper2
1
000030 [0.00076] gold over .000050 [0.00127] nickel—outer shell and socket center conductor;
.000030 [0.00076] gold over .000100 [0.00254] copper—pin center conductor.
000050 [0.00127] gold over .000050 [0.00127] nickel—outer shell and socket center conductor;
.000050 [0.00127] gold over .000100 [0.00254] copper—pin center conductor.
2
* Use hand actuated Power Unit Part No. 189721-2 or foot actuated Power Unit Part No. 189722-2. Both
units require “C” Head Die Set Adapter Part No. 318161-1 and an Adapter Holder Part No. 356304-1
(with ratchet) or Part No. 189928-1 (without ratchet). Request Catalog 124208 for more information on
the 626 Pneumatic Tool System.
Note: A ferrule is required for each pin and socket.
Extraction Tool Part No. 305183
40
Catalog 82003
Revised 06-08
Dimensions are in millimeters
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
