NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Power Contacts
Type I, Crimp, Snap-In
.953
[24.21]
Ref.
.663
[16.84]
Max.
.150
Dia.
.449
[11.40]
[3.81]
Pin
±.001
.094
Dia.
±.025
[2.39
]
.222
[5.64]
Dia. Max.
Pin
.150
Dia.
.560
[14.25]
Max.
[3.81]
Socket
Accommodates
±.001
.094
±.025
]
[2.39
Dia. Pin
.222
[5.64]
Dia. Max.
.843
[21.41]
Ref.
Socket
Material
Size 12—Pin Diameter .094 [2.39] (Test Current, 23 Ampere)‡
Tooling Part No.
Contact Body - Bronze
Wire Size
Range
Loose Piece
Contact No.
Dies for
Retention Spring - Beryllium copper
Hand
Tool
Pneumatic
AWG
[mm2]
Pin
Socket
*
Tool
Finish
18-16
14-12
0.8-1.4
2-3
202421-1
202422-1
202418-1
202417-1
90122
90122
90121
90121
Contact Body - .000030 [0.00076]
gold over .000050 [0.00127] nickel.
Gold thickness controlled on socket O.D.
*Use hand actuated Power Unit Part No. 189721-2 or foot actuated Power
Unit Part No. 189722-2. Both units require “C” Head Die Set Adapter
Part No. 318161-1 and an Adapter Holder Part No. 356304-1 (with ratchet)
or Part No. 189928-1 (without ratchet). Request Catalog 124208 for more
information on the 626 Pneumatic Tool System.
Retention Spring - Nickel plated
Related Product Data
‡ Single contact, free-air test current; not to be construed as contact rating
current. Use only for testing. Refer to contact current carrying capability
information, page 7.
Application Tooling - Pages 90, 91
Technical Documents
108-10108 Product Specification
114-10037 Application Specification
Extraction Tool Part No. 305183-8 (Instruction Sheet 408-1216)
36
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
equivalent U.S. Customary Units.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
