AMP M Series
Pin and Socket Connectors
Power Contacts (Continued)
Type XII, Crimp, Snap-In
Cable-to-Cable
The Multimate features of the
High Current Type XII contact
have been designed to fit into
the existing AMP Connectors
such as CPC (Circular Plastic
Connector), CMC (Circular
Metal-Shell Connector), G
Series, and M Series housings.
An initial T-Rise test in free air
has shown a 60 amp capability
with a 30° T-Rise with 8 gage
wires. The contact may be
crimped onto 8 AWG wire with
a Daniels Hand Tool M310 or
AMP P/N 356114-1 and
Standard
Type XII Socket
(Page 38)
Standard
Type XII Pin
(Page 38)
High Current
Type XII Socket
Part No. 193990-2
Positioner TP1068S or AMP P/N
356119-1.
Material
Body - Copper alloy
Louvertac Band -
Beryllium copper
Retention Spring -
Stainless steel
High Current
Type XII Pin
Part No. 193991-4
Finish
Body - Silver
Louvertac Band - Gold
Extraction Tool
Part No. 224155-1
Current-Carrying Capacity.
The graph shows current-car-
rying capacity versus
Notes: 1. High Current contacts with Louvertac bands are not intermateable with any other contact.
2. Additional information on CPC and CMC connectors is available in Tyco Electronics Catalog No. 82021.
3. Additional information on G Series connectors is available in Tyco Electronics Catalog No. 82046.
4. Additional information on M Series connectors is available in Tyco Electronics Catalog No. 82003.
5. Additional information on LGH connectors is available in Tyco Electronics Catalog No. 82024.
temperature rise for a fully
energized 3 position CPC
plug P/N 206037-2 and
receptacle P/N 206036-2.
These initial representative
amperage ratings were con-
ducted with 8 AWG wires
that were 3 feet long.
38
Catalog 82003
Revised 06-08
Dimensions are in millimeters
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
