NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Coaxial Contacts (Continued)
Miniature, Crimp,
Snap-In, Size 12
.865
Ref.
[21.97]
.005
[0.127]
Max.
.199
[5.05]
Dia.
±.005
.171
[4.35
.231
[5.87]
Dia.
Ref. Dia.
±0.127
]
Pin
1.118
[28.4]
Ref.
Pin
.040±.002
[1.02±0.05
]
Socket
.226
Ref. Dia.
.199
[5.05]
Dia.
[5.75]
Over Sleeve
Dust Cap
Ferrule
Retention Spring
Part No. 201142-1
Socket
Material
Outer Shell - Brass per
MIL-C-50
.425
[10.80]
Ref.
Center Conductor - Brass per
QQ-B-626
Inner Dielectric -
Polymethylpentene
Retention Spring - Beryllium
copper per QQ-C-533
Ferrule
Ferrule - Copper per QQ-C-576
Finish
Outer Shell, Center Conductor
- See charts on next page
Retention Spring - Nickel per
QQ-N-290
Ferrule - Tin per MIL-T-10727
Extraction Tool Part No.
305183-8
41
Catalog 82003
Dimensions are in millimeters
and inches unless otherwise
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
USA: 1-800-522-6752
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
UK: 44-141-810-8967
Revised 06-08
Canada: 1-905-470-4425
Mexico: 01-800-733-8926
C. America: 52-55-5-729-0425
specified. Values in brackets are
equivalent U.S. Customary Units.
