AMP M Series
Pin and Socket Connectors
Signal Contacts (Continued)
+.0010
Enhanced High Current
Type III+, Crimp, Snap-In
.0625
-.0020
Dia.
Spring, Stainless Steel
Pin Body
+0.025
-0.051
[
]
1.588
Spring, Stainless Steel
.390
Min.
[
]
9.91
Ferrule, Brass, Nickel Flash
.113 Max.
[
]
Dia.
2.87
Pin
±
.010
.530
±
0.25
[
]
13.46
Pin
Socket
Socket
Material and Finish - See chart
Contact Body - Copper Nickel Alloy
Retention Spring - Stainless steel
Related Product Data
Application Tooling - Pages 76-79
Technical Documents
114-10004 application Specification
108-10024-2 Product Specification
Ratings
Base Current:
Type III+ contacts: 13 amperes, 30˚C temperature rise with single contact on 14 AWG wire in free air
Enhanced High Current Type III+ contacts: 24 amperes, 30˚C temperature rise with single contact on 14 AWG wire
-55˚C to +105˚C
Temperature:
33
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
equivalent U.S. Customary Units.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
