Sterling-LWB5 Module
Datasheet
2.4 GHz WLAN Receiver Characteristics
(TA = +25°C, VBAT = 3.3V, VDDIO = 1.8V)
Parameter
Test Conditions
Min
Typ
Max
Unit
1 Mbps DSSS (b) RX Sensitivity
2 Mbps DSSS (b) RX Sensitivity
5.5 Mbps DSSS (b) RX Sensitivity
11 Mbps DSSS (b) RX Sensitivity
8% PER, 20 MHz
8% PER, 20 MHz
8% PER, 20 MHz
8% PER, 20 MHz
-
-
-
-
-93
-91
-90
-87
-
-
-
-
dBm
dBm
dBm
dBm
6 Mbps OFDM (g) RX Sensitivity
9 Mbps OFDM (g) RX Sensitivity
12 Mbps OFDM (g) RX Sensitivity
18 Mbps OFDM (g) RX Sensitivity
24 Mbps OFDM (g) RX Sensitivity
36 Mbps OFDM (g) RX Sensitivity
48 Mbps OFDM (g) RX Sensitivity
54 Mbps OFDM (g) RX Sensitivity
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
-
-
-
-
-
-
-
-
-90
-89
-87
-85
-82
-78
-74
-73
-
-
-
-
-
-
-
-
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
MCS0 (6.5 Mbps) OFDM (n) RX Sensitivity
MCS1 (13 Mbps) OFDM (n) RX Sensitivity
MCS2 (19.5 Mbps) OFDM (n) RX Sensitivity
MCS3 26 Mbps OFDM (n) RX Sensitivity
MCS4 39 Mbps OFDM (n) RX Sensitivity
MCS5 52 Mbps OFDM (n) RX Sensitivity
MCS6 58.5 Mbps OFDM (n) RX Sensitivity
MCS7 65 Mbps OFDM (n) RX Sensitivity
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
10% PER, 20 MHz
-
-
-
-
-
-
-
-
-90
-88
-85
-82
-78
-74
-72
-71
-
-
-
-
-
-
-
-
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
802.11b RX Overload Level – 20 MHz
802.11g RX Overload Leve l – 20 MHz
802.11n RX Overload Level – 20 MHz
8% PER, 11 Mbps
10% PER, 54 Mbps
10% PER, MCS7
-10
-20
-20
-
-
-
-
-
-
dBm
dBm
dBm
Table 17 2.4 GHz WLAN Receiver RF Characteristics
The information in this document is subject to change without notice.
330-0208-R2.1 Copyright © 2016-2018 LSR
Page 39 of 80
