Sterling-LWB5 Module
Datasheet
Bluetooth RF Characteristics
Bluetooth Transmitter Characteristics
(TA = +25°C, VBAT = 3.3V, VDDIO = 1.8V)
Parameter
Test Conditions
Min
Typical
Max
Unit
Transmit Frequency
Tamb = +25°C, 3.3V
Tamb = +25°C, 3.3V
Tamb = +25°C, 3.3V
Tamb = +25°C, 3.3V
Tamb = +25°C, 3.3V
2402
-
2480
MHz
dBm
dBm
dB
Bluetooth 1 Mbps GFSK Transmit Power
Bluetooth EDR Transmit Power
-
-
8
7
-
-
Bluetooth EDR Relative Transmit Power
Bluetooth Low Energy (BLE) Transmit Power
-4
-
1
-
6
dBm
Table 19 Bluetooth Transmitter RF Characteristics
Bluetooth Receiver Characteristics
(TA = +25°C, VBAT = 3.3V, VDDIO = 1.8V)
Parameter
Test Conditions
Min
Typical
Max
Unit
Receive Frequency
Tamb = +25°C, 3.3V
BER=0.1%
2402
-
2480
MHz
dBm
dBm
dBm
dBm
Bluetooth 1 Mbps GFSK Sensitivity
Bluetooth 2 Mbps EDR Sensitivity
Bluetooth 3 Mbps EDR Sensitivity
Bluetooth Low Energy (BLE) Sensitivity
-
-
-
-
-88
-90
-84.5
-92
-
-
-
-
BER=0.01%
BER=0.01%
Tamb = +25°C, 3.3V
Table 20 Bluetooth Receiver RF Characteristics
The information in this document is subject to change without notice.
330-0208-R2.1 Copyright © 2016-2018 LSR
Page 43 of 80
