Sterling-LWB5 Module
Datasheet
Parameter
Test Conditions
Min Typ Max
Unit
40.5/87.8 Mbps QPSK 802.11(ac) Mask Compliance
-13 dB EVM RMS power over TX packet, 40/80 MHz
MCS2 OFDM (ac) TX Output Power
-
-
-
-
-
-
-
-
9.5
8.5
9.5
9.5
9.5
9.5
9.5
9.5
-
-
-
-
-
-
-
-
dBm
54/117 Mbps 16-QAM 802.11(ac) Mask Compliance
-16 dB EVM RMS power over TX packet, 40/80 MHz
MCS3 OFDM (ac) TX Output Power
MCS4 OFDM (ac) TX Output Power
MCS5 OFDM (n) TX Output Power
MCS6 OFDM (n) TX Output Power
MCS7 OFDM (n) TX Output Power
MCS8 OFDM (n) TX Output Power
MCS9 OFDM (n) TX Output Power
dBm
dBm
dBm
dBm
dBm
dBm
dBm
81/175.5 Mbps 16-QAM 802.11(ac) Mask Compliance
-19 dB EVM RMS power over TX packet, 40/80 MHz
108/234 Mbps 64-QAM 802.11(ac) Mask Compliance
-22 dB EVM RMS power over TX packet, 40/80 MHz
121.5/263.3 Mbps 64-QAM 802.11(ac) Mask Compliance
-25 dB EVM RMS power over TX packet, 40/80 MHz
135/292.5 Mbps 64-QAM 802.11(ac) Mask Compliance
-27 dB EVM RMS power over TX packet, 40/80 MHz
162/351Mbps 256-QAM 802.11(ac) Mask Compliance
-30 dB EVM RMS power over TX packet, 40/80 MHz
180/390 Mbps 256-QAM 802.11(ac) Mask Compliance
-32 dB EVM RMS power over TX packet, 40/80 MHz
Table 16 5 GHz WLAN Transmitter RF Characteristics
The information in this document is subject to change without notice.
330-0208-R2.1 Copyright © 2016-2018 LSR
Page 38 of 80
