Sterling-LWB5 Module
Datasheet
5 GHz WLAN Transmitter Characteristics
(TA = +25°C, VBAT = 3.3V, VDDIO = 1.8V)
Parameter
Test Conditions
Min Typ Max
Unit
6 Mbps BPSK 802.11(a) Mask Compliance
-5 dB EVM RMS power over TX packet, 20 MHz
6 Mbps OFDM (a) TX Output Power
9 Mbps OFDM (a) TX Output Power
12 Mbps OFDM (a) TX Output Power
18 Mbps OFDM (a) TX Output Power
24 Mbps OFDM (a) TX Output Power
36 Mbps OFDM (a) TX Output Power
48 Mbps OFDM (a) TX Output Power
54 Mbps OFDM (a) TX Output Power
-
-
-
-
-
-
-
-
15
15
15
15
15
15
15
15
-
-
-
-
-
-
-
-
dBm
9 Mbps BPSK 802.11(a) Mask Compliance
-8 dB EVM RMS power over TX packet, 20 MHz
dBm
dBm
dBm
dBm
dBm
dBm
dBm
12 Mbps QPSK 802.11(a) Mask Compliance
-10 dB EVM RMS power over TX packet, 20 MHz
18 Mbps QPSK 802.11(a) Mask Compliance
-13 dB EVM RMS power over TX packet, 20 MHz
24 Mbps 16-QAM 802.11(a) Mask Compliance
-16 dB EVM RMS power over TX packet, 20 MHz
36 Mbps 16-QAM 802.11(a) Mask Compliance
-19 dB EVM RMS power over TX packet, 20 MHz
48 Mbps 64-QAM 802.11(a) Mask Compliance
-22 dB EVM RMS power over TX packet, 20 MHz
54 Mbps 64-QAM 802.11(a) Mask Compliance
-25 dB EVM RMS power over TX packet, 20 MHz
6.5 Mbps BPSK 802.11(n/ac) Mask Compliance
-5 dB EVM RMS power over TX packet, 20 MHz
MCS0 OFDM (n/ac) TX Output Power
MCS1 OFDM (n/ac) TX Output Power
MCS2 OFDM (n/ac) TX Output Power
MCS3 OFDM (n/ac) TX Output Power
MCS4 OFDM (n/ac) TX Output Power
MCS5 OFDM (n/ac) TX Output Power
MCS6 OFDM (n/ac) TX Output Power
MCS7 OFDM (n/ac) TX Output Power
MCS8 OFDM (ac) TX Output Power
-
-
-
-
-
-
-
-
-
13
13
13
13
13
13
13
13
13
-
-
-
-
-
-
-
-
-
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
dBm
13 Mbps QPSK 802.11(n/ac) Mask Compliance
-10 dB EVM RMS power over TX packet, 20 MHz
19.5 Mbps QPSK 802.11(n/ac) Mask Compliance
-13 dB EVM RMS power over TX packet, 20 MHz
26 Mbps 16-QAM 802.11(n/ac) Mask Compliance
-16 dB EVM RMS power over TX packet, 20 MHz
39 Mbps 16-QAM 802.11(n/ac) Mask Compliance
-19 dB EVM RMS power over TX packet, 20 MHz
52 Mbps 64-QAM 802.11(n/ac) Mask Compliance
-22 dB EVM RMS power over TX packet, 20 MHz
58.5 Mbps 64-QAM 802.11(n/ac) Mask Compliance
-25 dB EVM RMS power over TX packet, 20 MHz
65 Mbps 64-QAM 802.11(n/ac) Mask Compliance
-27 dB EVM RMS power over TX packet, 20 MHz
78 Mbps 64-QAM 802.11(n/ac) Mask Compliance
-30 dB EVM RMS power over TX packet, 20 MHz
13.5/29.3 Mbps BPSK 802.11(ac) Mask Compliance
-5 dB EVM RMS power over TX packet, 40/80 MHz
MCS0 OFDM (ac) TX Output Power
MCS1 OFDM (ac) TX Output Power
-
-
9.5
9.5
-
-
dBm
dBm
27/58.5 Mbps QPSK 802.11(ac) Mask Compliance
-10 dB EVM RMS power over TX packet, 40/80 MHz
The information in this document is subject to change without notice.
330-0208-R2.1 Copyright © 2016-2018 LSR
Page 37 of 80
