APPLICATIONS INFORMATION
General
LT1585/LT1587 frequency compensation optimizes fre-
quency response with low ESR capacitors. In general, use
capacitors with an ESR of less than 1Ω.
The LT1584/LT1585/LT1587 family of three-terminal
regulatorsiseasytouseandhasalltheprotectionfeatures
expected in high performance linear regulators. The de-
vices are short-circuit protected, safe-area protected, and
provide thermal shutdown to turn off the regulators
shouldthejunctiontemperatureexceedabout150°C. The
LT1584/LT1585/LT1587 family includes adjustable and
fixed voltage versions.
On the adjustable LT1584/LT1585/LT1587, bypassing the
adjust terminal improves ripple rejection and transient
response. Bypassing the adjust pin increases the required
output capacitor value. The value of 22µF tantalum or
100µF aluminum covers all cases of bypassing the adjust
terminal. With no adjust pin bypassing, smaller values of
capacitors provide equally good results.
These ICs are pin compatible with the LT1083/LT1084/
LT1085 family of linear regulators but offer lower dropout
voltage and faster transient response. The trade-off for this
improved performance is a 7V maximum supply voltage.
Similar to the LT1083/LT1084/LT1085 family, the LT1584/
LT1585/LT1587 regulators require an output capacitor for
stability. However, the improved frequency compensation
permitstheuseofcapacitorswithmuchlowerESRwhilestill
maintaining stability. This is critical in addressing the needs
of modern, low voltage, high speed microprocessors.
Normally, capacitor values on the order of several hundred
microfarads are used on the output of the regulators to
ensure good transient response with heavy load current
changes. Output capacitance can increase without limit
andlargervaluesofoutputcapacitancefurtherimprovethe
stability and transient response of the LT1584/LT1585/
LT1587 family.
Large load current changes are exactly the situation pre-
sented by modern microprocessors. The load current step
contains higher order frequency components that the
output decoupling network must handle until the regulator
throttles to the load current level. Capacitors are not ideal
elements and contain parasitic resistance and inductance.
These parasitic elements dominate the change in output
voltage at the beginning of a transient load step change.
The ESR of the output capacitors produces an instanta-
neous step in output voltage (∆V = ∆I × ESR). The ESL of
the output capacitors produces a droop proportional to the
rate of change of output current (V = L × ∆I/∆t). The output
capacitance produces a change in output voltage propor-
tional to the time until the regulator can respond (∆V = ∆t
× ∆I/C). These transient effects are illustrated in Figure 1.
Current generation microprocessors cycle load current
from almost zero to amps in tens of nanoseconds. Output
voltage tolerances are tighter and include transient re-
sponse as part of the specification. The LT1584/LT1585/
LT1587 family is specifically designed to meet the fast
current load-step requirements of these microprocessors
and saves total cost by needing less output capacitance in
order to maintain regulation.
Stability
The circuit design in the LT1584/LT1585/LT1587 family
requires the use of an output capacitor as part of the
frequency compensation. For all operating conditions, the
addition of a 22µF solid tantalum or a 100µF aluminum
electrolytic on the output ensures stability. Normally, the
LT1584/LT1585/LT1587 can use smaller value capacitors.
Many different types of capacitors are available and have
widely varying characteristics. These capacitors differ in
capacitor tolerance (sometimes ranging up to ±100%),
equivalent series resistance, equivalent series inductance,
and capacitance temperature coefficient. The LT1584/
ESR
EFFECTS
ESL
CAPACITANCE
EFFECTS
EFFECTS
LT1584 • F01
V
t
∆I
C
SLOPE,
=
POINT AT WHICH REGULATOR
TAKES CONTROL
Figure 1
