LTC2057/LTC2057HV
pin FuncTions
MS8 and S8/DD8
SD (Pin 1/Pin 1): Shutdown Control Pin.
–IN (Pin 2/Pin 2): Inverting Input.
+IN (Pin 3/Pin 3): Non-Inverting Input.
SDCOM (Pin 8/Pin 8): Reference Voltage for SD.
+
V (Pin 7/Pin 7): Positive Power Supply.
OUT (Pin 6/Pin 6): Amplifier Output
–
V (Pin 4/Pin 4, 9): Negative Power Supply.
NC (Pin 5/Pin 5): No Internal Connection.
MS10
GRD (Pin 1): Guard Ring. No Internal Connection.
–IN (Pin 2): Inverting Input.
SD (Pin 10): Shutdown Control Pin.
SDCOM (Pin 9): Reference Voltage for SD.
+
+IN (Pin 3): Non-Inverting Input.
GRD (Pin 4): Guard Ring. No Internal Connection.
V (Pin 8): Positive Power Supply.
NC (Pin 7): No Internal Connection.
OUT (Pin 6): Amplifier Output.
–
V (Pin 5): Negative Power Supply.
