Specifications ispGDX160V
External Timing Parameters (Continued)
ispGDX160V timings are specified with a GRP load apply to any signal path traversing the GRP (MUXA-D,
(fanout) of four I/O cells. The figure below shows the OE, CLK/CLKEN, MUXsel0-1). Global Clock signals
GRP Delay with increased GRP loads. These deltas which do not use the GRP have no fanout delay adder.
ispGDX160V Maximum GRP Delay vs. I/O Cell Fanout
10
8
6
4
2
0 4 10
20 30
40 50 60 70
I/O Cell Fanout
19
