D Subminiature
D*
Solder Cup Termination (Machined) with Tin Shells
Plug
Part Numbers
Clinch Nut
Clinch Nut
M3
Shell Size
DE
Layout
9
Through Hole
DE9PK87
# 4-40 UNC
DEE9PK87
DEX9PK87
DA
15
DA15PK87
DB25PK87
DC37PK87
DD50PK87
DAE15PK87
DBE25PK87
DCE37PK87
DDE50PK87
DAX15PK87
DBX25PK87
DCX37PK87
DDX50PK87
DB
25
DC
37
DD
50
Note: For performance class 2, add A191. Example: DA15PA191K87.
Selection Guide
ɀ For Product Features, Specifications,
Materials and Finishes, see pages 30-31.
Reader’s Resource
ɀ For contact cavity arrangements,
see page 224.
ɀ For panel cutouts, see page 221.
ɀ For hardware views (European),
see page 227.
Engaging Face
DD Configuration
A
C
B
5,69 (.224)
Ø 3,05 (.120)
2,84 (.112)
POSITION 1
D
E
L
10°
2,84 (.112)
10,72 (.422)
MAX
F
W
L
Dimensions
A
B
C
D
E
F
W
W
L
Shell Size
DE
0,38 (.015)
0,13 (.005)
0,13 (.005)
0,13 (.005)
0,38 (.015)
0,25 (.010)
0,368 (.0145)
0,41 (.016)
0,25 (.010)
30,81 (1.213)
39,14 (1.541)
53,04 (2.088)
69,32 (2.729)
66,93 (2.635)
16,92 (.666)
25,25 (.994)
38,96 (1.534)
55,42 (2.182)
52,81 (2.079)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
61,11 (2.406)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
11,07 (.436)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
10,72 (.422)
10,72 (.422)
10,82 (.426)
10,82 (.426)
10,82 (.426)
6,693 (.2635)
—
0,76 (.030)
0,76 (.030)
0,99 (.039)
0,99 (.039)
0,99 (.039)
DA
6,693 (.2635)
—
DB
—
—
—
6,84 (.269)
6,84 (.269)
6,84 (.269)
DC
DD
Dimensions are shown in mm (inch)
Dimensions subject to change
32
ITT [ ITT Cannon ]
