D Subminiature
D*A
Crimp Connectors without Contacts
Plug
Part Numbers
Shell Size
Layout
9
Through Hole
DEA9PK87FO
DAA15PK87FO
DBA25PK87FO
DCA37PK87FO
DE
DA
DB
DC
15
25
37
Note: For crimp (size 20) contacts and tooling, see pages 83 & 275.
Selection Guide
ɀ For Product Features, Specifications,
Materials and Finishes, see pages 30-31.
Reader’s Resource
ɀ For contact cavity arrangements,
see page 224.
ɀ For panel cutouts, see page 221.
ɀ For hardware views (Standard), see page 226.
Engaging Face
A
C
Ø 3,05 (.120)
B
POSITION 1
D
E
10°
K
10,93 (.430)
F
W
L
Dimensions
A
B
C
D
E
F
W
W
K
K
L
Shell Size
DE
0,38 (.015)
0,13 (.005)
0,13 (.005)
0,13 (.005)
0,38 (.015)
0,25 (.010)
0,368 (.0145)
0,41 (.016)
0,317 (.0125)
0,25 (.010)
0,25 (.010)
30,81 (1.213) 16,92 (.666)
39,14 (1.541) 25,25 (.994)
24,99 (.984)
8,36 (.329)
8,36 (.329)
8,36 (.329)
8,36 (.329)
11,07 (.436)
12,55 (.494)
12,55 (.494)
12,55 (.494)
12,55 (.494)
15,37 (.605)
10,72 (.422)
10,72 (.422)
10,82 (.426)
10,82 (.426)
10,82 (.426)
6,693 (.2635)
—
1,206 (.0475)
—
—
0,76 (.030)
0,76 (.030)
0,99 (.039)
0,99 (.039)
0,99 (.039)
DA
33,32 (1.312)
6,693 (.2635)
—
1,206 (.0475)
DB
53,04 (2.088) 38,96 (1.534) 47,04 (1.852)
69,32 (2.729) 55,42 (2.182) 63,50 (2.500)
66,93 (2.635) 52,81 (2.079) 61,11 (2.406)
—
—
—
6,84 (.269)
6,84 (.269)
6,84 (.269)
—
—
—
1,52 (.060)
1,52 (.060)
1,52 (.060)
DC
DD
Dimensions are shown in mm (inch)
Dimensions subject to change
