D Subminiature
ZD*
90° Solder Termination (Stamped) — European Footprint 10,2 mm
Receptacle
Part Numbers
Plastic Bracket,
Integrated Grounding
Strap, Boardlock,
Threaded Insert
# 4-40 UNC
Plastic Bracket,
Integrated Grounding
Strap, Boardlock,
Screw Lock
Shell Size
Layout
9
# 4-40 UNC
DE
DA
DB
DC
ZDEL9S-1AKN-146
ZDAL15S-1AKN-146
ZDBL25S-1AKN-146
ZDCL37S-1AKN-146
ZDE9S-1AKN-146
ZDA15S-1AKN-146
ZDB25S-1AKN-146
ZDC37S-1AKN-146
15
25
37
Selection Guide
ɀ For Product Features, Specifications,
Materials and Finishes, see pages 14-15.
Note: For contacts with -A191 microinches gold add -A191. Example: ZDEL9S-1AKN-A191-146
Reader’s Resource
ɀ For contact cavity arrangements,
see page 224.
ɀ For P.C. hole patterns, see page 273.
ɀ For panel cutouts, see page 221.
ɀ For hardware views (European),
see page 227.
2X SCREW LOCK
#4-40 UNC
9,77 - 9,27
( .385 - .365)
Engaging Face
A
C
8,15 - 7,65
(.321 - .301)
B
12,93 - 12,17
(.509 - .479)
1,00 (.039)
10°
2X GROUNDING HOOK
Dimensions
A
B
C
Shell Size
DE
0,38 (.015)
0,25 (.010)
16,33 (.643)
24,66 (.971)
38,38 (1.511)
54,84 (2.159)
0,13 (.005)
30,89 (1.216)
39,09 (1.539)
53,09 (2.090)
69,40 (2.732)
24,99 (.984)
33,32 (1.312)
47,04 (1.852)
63,50 (2.500)
DA
DB
DC
Dimensions are shown in mm (inch)
Dimensions subject to change
29
